• Model NO.：PH1720
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO
• Model：MHYV-xx
• Brand：OEM
• Od：4.8-5.0mm
• Jacket：PVC
• Length：305m
• Applications：Internet
• Transport Package：305m,Box
• Specification：COPPER; CCA; CCA+CCS; CCS conductor
• Trademark：phaeton OEM
• Origin：China
• HS Code：85444911
• Production Capacity：100, 000 Boxes,Year

Product Description:

Reted temperature: 60°C, 75°C,  90°c
Reference Standard: UL444,UL1581
Bare Solid copper conductor
RoHS/REACH Complied PVC,PE or LSZH Jacket
Complies to TIA/EIA-568-C.2& ISO/IEC 11801
Installation temperatu: -30°c±50°c
Minimum bending radius: >4P 4D Application:
100 Base-TX
100 Base-T4
100VG-AnyLAN
1000 Base-T(Gigabit Ethernet ATM)





 Content of Data SheetCategoryUTP CAT3-100 Pairs -PVC test StandardISO/IEC11801 TIA-568-C.2 YD/T1019ConductorMaterialSolid Bare copper Nom.O.D.(mm)0.500±0.005mm InsulationMaterialHDPEDiameter0.88±0.03mmSheathThickness0.50±0.05mmSheath Physical PropertiesBefore Aging Tensile Stength(Mpa)≥13.5
                      Elongation(%)≥150External O.D.19.8±0.4mmAging Period(°c×hrs) 100°c×24h×7dSurfaceClean,Frap,SatiationAfter Aging Tensile Stength(Mpa)≥12.5
                      Elongation(%)≥125MaterialPVCCold Bend(-20± 2°c× 4h 8×Cable O.D.ColorAccording to requiresElectrical Characteristics(20°C) 1.0-100.0MHz Impedance 100±15 ohmPrintingLetter Height3.0 ± 0.3mmDelay Shew(ns/100m) ≤45ColorBlackPrint error&Space≤±0.5%,1mNVP                              69%Core Color1 White-Blue/Blue2 White-Orange/OrangeCapacitance(nF/100m)max: 5.6PackingAs requiresDC Resistance(Ω/100m)max:9.5  Carton DimensionAs requiresPacking LengthAs requiresDC Conductor Resistance Unbalance(%)max 5.0  Rip-cordYESDrain WireNO


5.Technical Performance(100m):
 Frequency MHzRL ≥dBAttenuation ≤dB/100mNEXT ≥dB/100mPS NEXT ≥dB/100mImpedance
Ohms112.02.641.341.3100±15412.05.632.332.3812.08.527.827.81012.09.726.326.31610.013.323.323.3
FAQ:

Q1:Are you a trading company or manufacturer?
We are professional manufacturer for audio&video cable . also we supply of different electrical and electronic items

Q2: why will you choice us :
more than 15 years of professional teams will give you good quality products ,good service ,and reasonable price .

Q3:Can we have our logo or company name to be printed on your products or the package?

We offer OEM , ODM . our designer can make special design for you .

Q4: Is the MOQ fixed?
The MOQ is flexible and we accept small order as trial order.


Q5:Can I have a visit to you before the order?
Sure,welcome to visit our company ..
our company  is only one hour by train from shanghai
