Soft Cable Optical Fiber 0.2mm Breakout Cable Patch Cord Sc-LC 24f Breakout Patch Cord for Indoor
TOPNET (SHENZHEN) COMMUNICATION CO.,LTD- Application：Communication
- Type：Single-mode Fiber
- Connection Structure：SC
- Material Shape：Round Wire
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：100N<1000N
Base Info
- Model NO.：SC-LC 24f Breakout Patch Cord
- Core：Multicore
- Certification：RoHS, UL, CE, ISO9001
- Brand：OEM
- Sheath Material：LSZH, PVC
- Fiber Type Sm：G652D, G657A1, G657A2, G657b3
- Fiber Type mm：Om1, Om2, Om3, Om4, Om5
- Transport Package：Paper Carton
- Specification：5.0,6.0mm
- Trademark：Topnet
- Origin：China
- HS Code：8544700000
- Production Capacity：50000PCS Per Month
Description
Parameters
Standard Fiber Cable Assemblies
Fiber Type
SM(G.652/G.657A)
MM(OM1/OM2/OM3/OM4/OM5)
Jacket Materials
LSZH/OFNR/PVC
Connector Type
SC/LC/ST/LC/MU/DIN/SMA/MTRJ/MPO/E2000
Ferrule Materials
Ceramic
Testing Wavelengths
1310±30/1550±30nm
850±30/1300±30nm
Insertion Losss(dB)
TIA/EIA-455-107
≤ 0.25dB
(PC/UPC/APC)
≤ 0.3dB
(PC/UPC)
Return Loss(dB)
TIA/EIA-455-107
≥50dB(PC/UPC)
≥60dB(APC)
≥40dB(PC/UPC)
Exchangeability
≤ 0.2dB
Cable Assemblies
Pigtail/Simplex/Duplex/Fan-out Patchcord
Operating Temperature (° C)
-10~ + 70
Storage Temperature (° C)
-40 ~ +85
Package
1unit/bag
*All values specified are with connectors.
Package
