UL1571 Double PVC Copper Electric Cable Hook up Wire
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Electric Wire
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：UL1571
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Bort
- Color：White,as Request
- Factory：ISO 9001
- Standard：Reach,RoHS
- OEM/ODM：Accepted
- Delivery：7-12days
- Weight：3.4kgs,Roll
- Packing：as Request
- Sample Time：3-5days
- Sample：Supplied
- Transport Package：Rolls
- Specification：610m
- Trademark：BORT
- Origin：China
- HS Code：85444929
- Production Capacity：300, 000km, Year
Description
AWGNo.of Cond Insulation Nom.Thick. Insulation Nom. Thick. Jacket Nom. Dia. mm mm mm mm Ω/mm 36 7/0.05 0.45 _ _ 1490 34 7/0.065 0.50 _ _ 908 32 7/0.08 0.70 _ _ 597 30 7/0.1 0.90 0.35 354.0 30 7/0.1 0.70 _ _ 354.0 28 7/0.127 0.90 0.35 1.80 223.0 28 7/0.127 0.90 _ _ 223.0 26 7/0.16 1.00 _ _ 139.0 24 7/0.2 1.10 _ _ 88.9 22 7/0.16 1.40 0.58 2.8 57.5 22 17/0.16 1.25 _ _ 57.5 20 26/0.16 1.80 0.56 3.1 34.6 18 65/0.127 1.78 0.59 3.2 23.3 16 54/0.18 2.15 0.61 3.6 15.1
