0.6/1kv, Four Cores, Copper Conductor, PVC Insulated, Copper Wire Braid PVC Sheathed Nyjy Power Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground, Static Outdoor Application
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：NYJY
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, CCC, RoHS, VDE
- Brand：Fengda
- Colour：Red,Green,Blue,Black,White,as Request
- Flame Test：Yes
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Factory Type：Manufacturer
- Transport Package：Rolls or According to Cusotmers′ Reques
- Specification：1.5 to 300mm2
- Trademark：fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：5000000km,Year
Description
NYCY PVC PVC 0.6/1kV Power Cable
APPLICATION
For use indoors, in cable ducts, outdoors and in ground
for power plants, industrial plants, as well as in local power
networks, if increased electrical protection is required.
CHARACTERISTICS
Voltage Rating Uo/U
0.6/1kV
Temperature Rating
Fixed: -20°C to +70°C
Flexed: -5°C to +70°C
Laboratory
Minimum Bending Radius
15 x overall diameter
CONSTRUCTION
Conductor
RE: Class 1 solid copper conductor
Insulation
PVC (Polyvinyl Chloride)
Binding Tape
PVC (Polyvinyl Chloride)
Concentric Conductor
Copper wires and copper tape
Sheath
PVC (Polyvinyl Chloride)
Order- No. | Product | CPR Reaction to fire class | Cu No. [kg/km] | Outer diameter approx. [mm] | Net weight approx. [kg/km] | Rated short- time current (1s) [kA] | tensile force max. [daN] | Bending radius one-off min. [mm] | Bending radius repeated min. [mm] |
| 4123104 | NYCY-J 3x2,5 RE/2,5 0,6/1kV | Eca | 104.0 | 14.6 | 320.00 | 0.29 | 38 | 90 | 180 |
| 4121604 | NYCY-J 5x1,5 RE/1,5 0,6/1kV | Eca | 95.0 | 15.5 | 345.00 | 0.17 | 38 | 100 | 200 |
| 4146804 | NYCY-J 5x2,5 RE/2,5 0,6/1kV | Eca | 152.0 | 16.4 | 420.00 | 0.29 | 63 | 105 | 210 |
| 4123004 | NYCY-J 5x4 RE/4 0,6/1kV | Eca | 238.0 | 19.3 | 600.00 | 0.46 | 100 | 120 | 240 |
| 4123404 | NYCY-J 5x6 RE/6 0,6/1kV | Eca | 355.0 | 21.1 | 765.00 | 0.69 | 150 | 135 | 270 |
| 4125204 | NYCY-J 5x6 RE/16 0,6/1kV | Eca | 462.0 | 21.5 | 860.00 | 0.69 | 150 | 135 | 270 |
| 4153500 | NYCY-J 7x1,5 RE/2,5 0,6/1kV | Eca | 133.0 | 16.3 | 410.00 | 0.17 | 53 | 105 | 210 |
| 4147801 | NYCY-J 7x4 RE/4 0,6/1kV | Eca | 315.0 | 20.1 | 715.00 | 0.46 | 140 | 130 | 260 |
| 4146101 | (N)YCY-J 12x1,5 RE/1,5 0,6/1kV | Eca | 211.0 | 19.8 | 590.00 | 0.17 | 90 | 120 | 240 |
| 4147101 | (N)YCY-J 12x2,5 RE/2,5 0,6/1kV | Eca | 348.0 | 21.3 | 745.00 | 0.29 | 150 | 130 | 260 |
| 4174900 | NYCY-J 19x1,5 RE/4 0,6/1kV | Eca | 320.0 | 22.5 | 785.00 | 0.17 | 144 | 140 | 280 |
| 4147110 | NYCY-J 24x1,5 RE/10 0,6/1kV | Eca | 466.0 | 26.2 | 1015.00 | 0.18 | 186 | 165 | 330 |
| 4167500 | NYCY-J 24x2,5 RE/10 0,6/1kV | Eca | 696.0 | 28.4 | 1290.00 | 0.29 | 302 | 175 | 350 |
| 4119100 | NYCY-J 61x1,5 RE/10 0,6/1kV | Eca | 998.0 | 35.8 | 2055.00 | 0.17 | 464 | 220 | 440 |
