Optical Fiber Cable ADSS 48 Cores Single Mode G657A1 G657A2 FRP Strength Member Double Jacket Outdoor Price
Hanyang (Hangzhou) Cable Co., Ltd.- Type：Single-mode Fiber
- Connection Structure：MTRJ
Base Info
- Model NO.：ADSS fiber cable
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：>10000N
- Core：Multicore
- Certification：RoHS, UL, CE, ISO9001
- Brand：Superlink ,OEM
- Sheath Material：PE
- Fiber Count：48
- Cable Diameter：8.0
- Cable Weight：78
- Transport Package：Drum
- Specification：ADSS
- Trademark：SUPERLINK , OEM
- Origin：Hangzhou
- HS Code：8544700000
- Production Capacity：5000km,Month
- Package size per unit product：10.00cm * 10.00cm * 1.00cm
- Gross weight per unit product：0.200kg
Description
G.652
G.655
50/125μm
62.5/125μm
Attenuation
(+20ºC)
@850nm
≤3.0 dB/km
≤3.0 dB/km
@1300nm
≤1.0 dB/km
≤1.0 dB/km
@1310nm
≤0.36 dB/km
≤0.40 dB/km
@1550nm
≤0.22 dB/km
≤0.23dB/km
Bandwidth (Class A)
@850nm
≥500 MHz·km
≥200 MHz·km
@1300nm
≥1000 MHz·km
≥600 MHz·km
Numerical Aperture
0.200±0.015NA
0.275±0.015NA
Cable Cut-off Wavelength λcc
≤1260nm
≤1480nm
172
Note: G.652D fiber in the table, the fiber type can also be specified according to customer requirements.
1. What's your company MOQ?- Our MOQ is 30km. But MOQ of stocks are 1 pcs.
2. Can you do our design?
- Of course, your customized design (OEM) is available.
3. What's the lead-time for order delivery?
- Within 10~30days.
4. Can you send a sample for us?
- Yes, we can provide free samples.
5. What is your packaging?
- Our packaging includes PE film, shrink bag, pull box, paper reel, plastic reel, wooden reel. Depends
on what you want!
6. Delivery time and transportation method?
- Shipment can be arranged immediately. By express, by sea, by air, you can ship whatever you want.
7.Payment method?
- T/T, L/C, we also accept most other convenient methods of payment.
