• Model NO.：GS-21-11
• Material Shape：Round Wire
• Range of Application：Power Cable
• Certification：ISO9001, CE, CCC
• Brand：Suntay
• Transport Package：Standard Export Packing on Reel
• Specification：10-800mm2
• Trademark：Suntay
• Origin：Jiangsu, China
• HS Code：7614100000
• Production Capacity：100000tons,Year

Code Word

Size (AWG or KCMIL)

Stranding (Al/Stl)

Diameter (inches)

Weight Per 1000ft (lbs.)

Rated Strength (lbs.)

Resistance OHMS/1000ft.

Allowable Ampacity+ (Amps)

AL

Steel

Complete Cable

AL

Steel

Total

DC @ 20°C

AC @ 75°C

Turkey

6

6/1

.0661

.0661

.1980

24.5

11.6

36.1

1190

.641

.806

105

Swan

4

6/1

.0834

.0834

.2500

39.0

18.4

57.4

1860

.403

.515

140

Swanate

4

7/1

.0772

.1030

.2570

39.0

28.0

67.0

2360

.399

.519

140

Sparrow

2

6/1

.1052

.1052

.3160

62.0

29.3

91.3

2850

.254

.332

184

Sparate

2

7/1

.0974

.1298

.3250

62.0

44.7

106.7

3460

.251

.338

184

Robin

1

6/1

.1181

.1181

.3550

78.2

37.0

115.2

3550

.201

.268

212

Raven

1/0

6/1

.1327

.1327

.3980

98.7

46.6

145.3

4380

.159

.217

242

Quail

2/0

6/1

.1489

.1489

.4470

124.3

58.8

183.1

5310

.126

.176

276

Pigeon

3/0

6/1

.1672

.1672

.5020

156.7

74.1

230.8

6620

.100

.144

315

Penguin

4/0

6/1

.1878

.1878

.5630

197.7

93.4

291.1

8350

.0795

.119

357

Waxwing

266.8

18/1

.1217

.1217

.6090

250.3

39.2

289.5

6880

.0643

.0787

449

Partridge

266.8

26/7

.1013

.0788

.6420

251.7

115.6

367.3

11300

.0637

.0779

475

Ostrich

300.0

26/7

.1074

.0835

.6800

283.0

130.0

412.0

12700

.0567

.0693

492

Merlin

336.4

18/1

.1367

.1367

.6840

315.8

49.5

365.3

8680

.0510

.0625

519

Linnet

336.4

26/7

.1137

.0885

.7210

317.1

145.5

462.6

14100

.0505

.0618

529

Oriole

336.4

30/7

.1059

.1059

.7410

381.0

209.0

526.0

17300

.0502

.0613

535

Chickadee

397.5

18/1

.1486

.1486

.7430

373.1

58.5

431.6

9940

.0432

.0529

576

Brant

397.5

24/7

.1287

.0858

.7720

374.0

137.0

511.0

14600

.0430

.0526

584

lbis

397.5

26/7

.1236

.0962

.7930

374.7

171.9

546.6

16300

.0428

.0523

587

Lark

397.5

30/7

.1151

.1151

.8060

375.0

247.0

622.0

20300

.0425

.0519

594

Pelican

477.0

18/1

.1628

.1628

.8140

447.8

70.2

518.0

11800

.0360

.0442

646

Flicker

477.0

24/7

.1410

.094

.8460

449.0

164.0

614.0

17200

.0358

.0439

655

Hawk

477.0

26/7

.1354

.1053

.8580

449.6

206.4

656.0

19500

.0356

.0436

659

Hen

477.0

30/7

.1261

.1261

.8830

451.1

296.3

747.4

23800

.0354

.0433

666

Osprey

556.5

18/1

.1758

.1758

.8790

522.0

82.0

603.0

13700

.0308

.0379

711

Parakeet

556.5

24/7

.1523

.1015

.9140

525.0

191.8

716.8

19800

.0307

.0376

721

Dove

556.5

26/7

.1463

.1138

.9270

525.0

241.0

766.0

22600

.0306

.0375

726

Eagle

556.5

30/7

.1362

.1362

.9530

525.0

345.0

871.0

27800

.0303

.0372

734

Peacock

605.0

24/7

.1588

.1059

.9530

570.0

209.0

779.0

21600

.0282

.0346

760

Squab

605.0

26/7

.1525

.1186

.9660

570.0

262.0

832.0

24300

.0281

.0345

765

Wood Duck

605.0

30/7

.1420

.1420

.9940

571.0

375.0

946.0

28900

.0279

.0342

774

Teal

605.0

30/19

.1420

.0852

.9940

571.0

367.0

939.0

30000

.0279

.0342

773

Kingbird

636.0

18/1

.1880

.1880

.9400

597.2

93.6

690.8

15700

.0270

.0332

773

Swift

636.0

36/1

.1329

.1329

.9300

596.0

47.0

643.0

13690

.0271

.0334

769

Rook

636.0

24/7

.1628

.1085

.9770

600.0

219.2

819.2

22600

.0268

.0330

784

Grosbeak

636.0

26/7

.1564

.1216

.9900

600.0

275.2

875.2

25200

.0267

.0328

789

Scoter

636.0

30/7

.1456

.1456

1.0190

600.0

395.0

995.0

30400

.0256

.0325

798

Egret

636.0

30/19

.1456

.0874

1.0190

600.0

386.0

987.0

31500

.0266

.0326

798

Flamingo

666.6

24/7

.1667

.1111

1.0000

629.1

229.8

858.9

23700

.0256

.0315

807

Gannet

666.6

24/7

.1601

.1245

1.0140

629.0

289.0

916.0

26400

.0255

.0313

812

Stilt

715.5

24/7

.1727

.1151

1.0360

674.0

247.0

920.0

25500

.0239

.0294

844

Starling

715.5

26/7

.1659

.1290

1.0510

674.0

310.0

984.0

28400

.0238

.0292

849

Redwing

715.5

30/19

.1544

.0927

1.0810

676.0

435.0

1110.0

34600

.0236

.0290

859

Coot

795.0

36/1

.1486

.1486

1.0400

745.0

58.0

804.0

16710

.0217

.0268

884

Drake

795.0

26/7

.1749

.1360

1.1080

750.0

344.0

1094.0

31500

.0214

.0263

907

Tern

795.0

45/7

.1329

.0886

1.0630

749.0

146.0

895.0

22100

.0216

.0269

887

Condor

795.0

54/7

.1213

.1213

1.0920

749.0

274.0

1023.0

28200

.0215

.0272

889

Mallard

795.0

30/19

.1628

.0977

1.1400

751.0

483.0

1234.0

38400

.0213

.0261

918

Ruddy

900.0

45/7

.1414

.0943

1.1310

849.0

166.0

1015.0

24400

.0191

.0239

958

Canary

900.0

54/7

.1291

.1291

1.1620

849.0

310.0

1159.0

31900

.0190

.0241

961

Catbird

954.0

36/1

.1628

.1628

1.1400

896.0

70.0

966.0

--

--

--

--

Rail

954.0

45/7

.1456

.0971

1.1650

900.0

176.0

1076.0

25900

.0181

.0225

993

Cardinal

954.0

54/7

.1329

.1329

1.1960

900.0

329.0

1229.0

33800

.0179

.0228

996

Ortolan

1033.5

45/7

.1515

.1010

1.2120

974.0

190.0

1163.0

27700

.0167

.0209

1043

Curlew

1033.5

54/7

.1383

.1383

1.2440

974.0

356.0

1330.0

36600

.0165

.0211

1047

Bluejay

1113.0

45/7

.1573

.1048

1.2590

1050.0

205.0

1255.0

29800

.0155

.0194

1092

Finch

1113.0

54/19

.1436

.0861

1.2930

1055.0

376.0

1431.0

39100

.0154

.0197

1093

Bunting

1192.5

45/7

.1628

.1085

1.3020

1125.0

219.0

1344.0

32000

.0144

.0182

1139

Grackle

1192.5

54/19

.1486

.0892

1.3370

1129.0

402.0

1531.0

41900

.0144

.0184

1140

Bittern

1272.0

45/7

.1681

.1121

1.3450

1200.0

234.0

1434.0

34100

.0135

.0171

1184

Pheasant

1272.0

54/19

.1535

.0921

1.3810

1204.0

429.0

1633.0

43600

.0135

.0173

1187

Dipper

1351.5

45/7

.1733

.1155

1.3860

1273.0

248.0

1521.0

36200

.0127

.0162

1229

Martin

1351.5

54/19

.1582

.0949

1.4240

1279.0

456.0

1735.0

46300

.0127

.0163

1232

Bobolink

1431.0

45/7

.1783

.1189

1.4270

1348.0

263.0

1611.0

38300

.0120

.0153

1272

Lapwing

1590.0

45/7

.1880

.1253

1.5040

1498.0

292.0

1790.0

42200

.0108

.0139

1354

Falcon

1590.0

54/19

.1716

.1030

1.5440

1505.0

536.0

2041.0

54500

.0108

.0140

1359

Chukar

1780.0

84/19

.1456

.0874

1.6020

1685.0

386.0

2072.0

51000

.0097

.0125

1453

Bluebird

2156.0

84/19

.1602

.0962

1.7620

2040.0

468.0

2508.0

60300

.00801

.0105

1623

Kiwi

2167.0

72/7

.1735

.1157

1.7350

2051.0

249.0

2300.0

49800

.00801

.0106

1607

Code Word

Size (AWG or KCMIL)

Stranding (Al/Stl)

Diameter (inches)

Weight Per 1000ft (lbs.)

Rated Strength (lbs.)

Resistance OHMS/1000ft.

Allowable Ampacity+ (Amps)

AL

Steel

Complete Cable

AL

Steel

Total

DC @ 20°C

AC @ 75°C

Grouse

80.0

8/1

.1000

.1667

.367

75.1

73.9

149.0

5200

.207

.294

204

Petrel

101.8

12/7

.0921

.0921

.461

95.9

158.1

254.1

10400

.158

.250

237

Minorca

110.8

12/7

.0961

.0962

.481

103.9

172.1

276.6

11300

.145

.235

248

Leghorn

134.6

12/7

.1059

.1059

.530

126.9

209.1

336.0

13600

.120

.204

273

Guinea

159.0

12/7

.1151

.1151

.576

149.1

246.9

396.8

16000

.101

.181

297

Dotterel

176.9

12/7

.1214

.1214

.607

166.8

274.6

441.4

17300

.0911

.169

312

Dorking

190.8

12/7

.1261

.1261

.631

179.7

296.3

476.0

18700

.0845

.160

324

Brahma

203.2

16/19

.1127

.0977

.714

191.7

485.1

675.8

---

---

---

---

Cochin

211.3

12/7

.1327

.1327

.663

198.8

328.2

527.0

28400

.0763

.150

340

+Conductor temperature of 75 C, ambient temperature 25 C, emissivity 0.5, wind 2 ft./sec. in sun.

AAC, AAAC, ACSR, AACSR & ACAR conductor widely used in power transmission lines with various voltage levels.Since they have such good characteristics as simple structure, convenient installation and maintenance, low cost for the line, large transmission capacity and are also suitable for laying across rivers and valleys where special geographical teatures exist.

Conductor Specification:
(1) all aluminium conductor (AAC)
(2) all aluminimum alloy conductor(AAAC)

(3) aluminum conductor steel reinforced (ACSR)

(4) anti-corrosion type ACSR

(5) aluminimum conductor aluminimum clad steel reinforced(ACSR/AW)
(6)rear earth aluminimum conductor steel reinforced(ACSR/RE)
(7)aluminimum conductor aluminimum alloy reinforced(ACAR)

All Aluminum Conductor(AAC)& Aluminum Conductor Steel Reinforced(ACSR))for ASTM

(AAC, ACCR, AAAC, ACSR) Generally Confirming to IS 398 (Part-I, II, IV), IEC-228
(AAAC) Conductor as per ASTM-B-399-1992
(AAAC) Conductor as per BS-3242-1970
(AAAC) Conductor IS: 398-IV-1994
(ACSR) as per ASTM-B-233-1992
(AAC) as per BS-215-1-1970
(AAC) as per IS-398-1: 1976
(AAC) as per ASTM-B-231-1990
(ACSR) as per IS: 398-II: 1976 & IS: 398-V: 1992
(ACSR) BS-215-II-1970
(AACSR) as per IEC-1089-1191
AAC(All aluminum conductor) are suited for overhead power line.

Conductor Construction:
Aluminum alloy 1350-H-19 wires, concentrically stranded about a steel core. Core wire for ACSR is available with class A, B, or C galvanizing; ""aluminized"" aluminum coated (AZ); Or aluminum-clad (AW). Additional corrosion protection is available through the application of grease to the corrosion or infusion of the complete cable with grease.

We can supply this conductor according to different recognized standards,distribution and transmission lines for distributing power.
