• Model NO.：FA-DPYC FA-DPYCY FA-TPYC FA-TPYCY
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE, RoHS, UL, VDE
• Model：Yz,Yzw,Yc,Ycw
• Brand：Fengda
• OEM&ODM：Yes
• Conductor Standard：IEC 60228
• Colors：Assorted Upon Request
• Coductor：Tinned Annealed Stranded Copper
• Model Number：1,2,3cores
• Armor：Galvanized Steel Wire Braid
• Cabling：Insulated Conductors Shall Be Cabled
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：Copper
• Trademark：Fengda
• Origin：China
• HS Code：8544
• Production Capacity：80000 Meter,Meters Per Month

Classification

Code

Construction details

Conductor

D

Tinned Copper Wire JIS C3410

Insulation

P

EPR as per JIS C 3410

Sheath

Y

PVC as per JIS C 3410

Armor

C

Galvanized steel wire braided



CB

Tinned copper wire braided

Paint



The white paint should be painted uniformly

Covering

Y

PVC as per JIS C 3410



Color: Black

Standards

Nominal voltage (V)Maximum working voltage (V)(Test voltage) V/min.a.cd.c250V250V450V1500/50.6/1 kV0.6/1 kV0.9/1.5kV3500/5

Minimum Bending Radius

Type of cableMinimum bending radius Up to 1.8/3kVUnarmored or unbraided D ≤ 25mm4XDD > 25mm6XDMetal braid screened or armored6XDTape screened8XD3.6/6kVSingle core12XDabove3-core9XDNOTE) D : Overall diameter of cable



Application:

The cable is fixed installation, used for power, lighting and control in most area and open deck area in ship.

The description/sizes may be different with goods, please check with us when order.
