CE Certified PVC Insulated Data Cable Liyy for Low-Mechanical Stress

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Installation
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：LiYY
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemLiYY Data CableConductorBare Copper (as client's required)InsulationSpecial PVC (as client's required)Outer SheathSpecial PVC (as client's required)Specifications0.14mm2 up to 0.75mm2Nominal Voltage300VTest Voltage2000VTemperature Rating-5°C to +70ºC Minimum Bending Radius7.5 x cable diameterColorOptionalCertificationCECharacteristicFlame-retardant
Environmental protectionApplicationWidely suitable for fixed installation or flexible application in low-mechanical stress, no mechanical tension or load, non-dynamically controlled movable dry or humid environment. It is often used as control and signal cables in computer systems, electronic control equipment, and measuring equipment in office machines in the tool manufacturing and machinery industries.

CE Certified PVC Insulated Data Cable Liyy for Low-Mechanical StressCE Certified PVC Insulated Data Cable Liyy for Low-Mechanical Stress
CE Certified PVC Insulated Data Cable Liyy for Low-Mechanical Stress

CE Certified PVC Insulated Data Cable Liyy for Low-Mechanical StressCE Certified PVC Insulated Data Cable Liyy for Low-Mechanical StressCE Certified PVC Insulated Data Cable Liyy for Low-Mechanical StressCE Certified PVC Insulated Data Cable Liyy for Low-Mechanical StressCE Certified PVC Insulated Data Cable Liyy for Low-Mechanical StressCE Certified PVC Insulated Data Cable Liyy for Low-Mechanical Stress
