• Model NO.：Welding Cable flexible rubber cable
• Wire Core Material：Class 5 Copper Wire
• Certification：ISO, CCC, CE, UL
• Model：YC
• Brand：Yifang
• Certificate：ISO;Ce;UL;Kema
• Transport Package：Wood Packing by Sea
• Specification：1000meter per drum
• Trademark：Yifang
• Origin：China
• HS Code：8544492100
• Production Capacity：300km Per Month

Basic Info.

Model NO. Welding Cable flexible rubber cable Wire Core Material Class 5 Copper Wire Certification ISO, CCC, CE, UL Model YC Brand Yifang Certificate ISO;Ce;UL;Kema Transport Package Wood Packing by Sea Specification 1000meter per drum Trademark Yifang Origin China HS Code 8544492100 Production Capacity 300km Per Month

Product Description

Welding Cable

Welding cable is used in welding machines and connection pliers. Low voltage is not more than AC 200V and DC peak value is 400V. The long time remissible operating temperature is not more than 65 degrees. The product is suitable for welding machines where the voltage to the ground is not more than DC 200V and the pulsating current value is 400V.

Construction
The welding cable is made of copper conductor and natural rubber sheath. It can also be made of copper conductor, chloroprene rubber or other syntheitic sheath.

Nominal Section Area (mm2)	Copper Wire No./Dia. (mm)	Insulated Sheath Thickness (mm)	Average of the Max. Outer Dia. (mm)	Conductor Resistance at 20ºC (≤Ω/km)	Weight (kg/km)
10	322/0.20	1.8	9.7	1.91	151.6
16	513/0.20	2.0	11.5	1.61	224.0
25	798/0.20	2.0	13.0	0.758	326.0
35	1121/0.20	2.0	14.5	0.536	430.0
50	1596/0.20	2.2	17.0	0.379	600.0
70	2214/0.20	2.4	19.5	0.268	818.1
95	2297/0.20	2.6	22.0	0.198	1082.7

Package
The welding cable comes in coils.
