• Model NO.：Cable LXHIOZ1
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, SGS
• Model：Cable Lxhioz1
• Brand：Hongda
• Conductor：Class 2 Stranded Aluminium Conductor
• Inner Semi-Conductive Layer：Semi-Conductive Material
• Insulation：XLPE (Cross-Linked Polyethylene)
• Outer Semi-Conductive Layer：Semi-Conductive Material
• Screen：Copper Wires
• Sheath：PVC (Polyvinyl Chloride)
• Transport Package：Steel & Wooden Drum
• Specification：16mm2 to 400mm2
• Trademark：Hongda Cable
• Origin：Made in China
• HS Code：8544601200
• Production Capacity：200km,Month

Basic Info.

Model NO. Cable LXHIOZ1 Wire Core Material Bare Copper Wire Certification ISO, CCC, SGS Model Cable Lxhioz1 Brand Hongda Conductor Class 2 Stranded Aluminium Conductor Inner Semi-Conductive Layer Semi-Conductive Material Insulation XLPE (Cross-Linked Polyethylene) Outer Semi-Conductive Layer Semi-Conductive Material Screen Copper Wires Sheath PVC (Polyvinyl Chloride) Transport Package Steel & Wooden Drum Specification 16mm2 to 400mm2 Trademark Hongda Cable Origin Made in China HS Code 8544601200 Production Capacity 200km/Month

Product Description

LXHIOZ1 Unarmoured PO Single Core Fire Retardant Halogen Free Aluminium Cable with Copper Wire Screen 3.6/6 (7.2) kV up to 18/30 (36) kV

Cabo LXHIOZ1, Fire Retardant
DESCRIPTION:

LXHIOZ1 Unarmoured PO Single Core Fire Retardant Halogen Free Aluminium Cable with Copper Wire Screen 3.6/6 (7.2) kV up to 18/30 (36) kV - Cable for power distribution and power supply stations, halogen free and fire retardant used in Utility and Industrial applications, for rated voltages up to 18/30kV. Applicable for installations of high security in relation to fire, namely tunnels, underground railways.
A = Voltage U0/U(Um) [kV]
B = Outer Diameter [mm]
C = Conductor Cross-section [mm2]
D = Diameter Over Insulation [mm]
E = Current Carrying Capacity - In Air (A)
Ambient Temperature for cables in air = 30°C


Electrical Characteristic



CONDUCTOR MATERIAL	Aluminium
CONDUCTOR CLASS	Circular, Stranded Class 2
INSULATION	XLPE - Cross-linked Polyethylene
METALLIC SCREEN	Copper Wire Screen - Annealed Copper Wires Helicaly Wound and Equalising Copper Tape Applied in Open Counter-helix. Plastic Tape is Applied Over Screen
OVERSHEATH	LSHF Low Smoke Halogen Free Thermoplastic Compound, Polyolefin Type DMZ2
OVERSHEATH COLOUR	Black
CABLE DESIGNATION	Al, Cu Tape Screen, PO, XLPE
TEST VOLTAGE	3.5xUo
CONDUCTOR OPERATING TEMP	90°C (nominal) to 120°C (2)
MAX SHORT-CIRCUIT TEMP	250°C (t<5s)
AMBIENT TEMPERATURE	Cables in Air 30°C
MAX PULLING FORCE (N)	30xConductor Cross-section [mm2] Over Conductor (N)
BEDDING	LSHF Low Smoke Halogen Free Thermoplastic Compound
FIRE RETARDANT	Bunch of Cables Vertically Mounted on a Ladder, Length of Charred Cable <2.5m

Dimensions:
A = Voltage U0/U(Um) [kV]
B = Outer Diameter [mm]
C = Conductor Cross-section [mm2]
D = Diameter Over Insulation [mm]
E = Current Carrying Capacity - In Air (A)

PART NUMBER	A	B	C	D	E	UNIT
LXHIOZ1-1X32.0	6/10 (12)	31.5mm	70mm	18.0mm	225	Meter
LXHIOZ1-1X33.5	6/10 (12)	33.5mm	95mm	20.0mm	274	Meter
LXHIOZ1-1X35.5	6/10 (12)	35.0mm	120mm	21.5mm	319	Meter
LXHIOZ1-1X36.5	6/10 (12)	36.5mm	150mm	23.0mm	361	Meter
LXHIOZ1-1X38.0	6/10 (12)	38.0mm	185mm	24.5mm	415	Meter
LXHIOZ1-1X41.0	6/10 (12)	40.5mm	240mm	26.5mm	493	Meter
LXHIOZ1-1X43.5	6/10 (12)	43.5mm	300mm	29.5mm	573	Meter
LXHIOZ1-1X47.0	6/10 (12)	46.5mm	400mm	32.5mm	671	Meter
LXHIOZ1-1X50.0	6/10 (12)	50.0mm	500mm	35.5mm	783	Meter
LXHIOZ1-1X53.5	6/10 (12)	54.5mm	630mm	40.0mm	926	Meter
LXHIOZ1-1X40.0	12/20 (24)	39.5mm	120mm	26.0mm	325	Meter
LXHIOZ1-1X42.5	12/20 (24)	42.5mm	185mm	28.5mm	422	Meter
LXHIOZ1-1X45.0	12/20 (24)	45.0mm	240mm	31.0mm	499	Meter
LXHIOZ1-1X48.0	12/20 (24)	48.0mm	300mm	34.0mm	579	Meter
LXHIOZ1-1X51.0	12/20 (24)	51.0mm	400mm	36.5mm	677	Meter
LXHIOZ1-1X54.5	12/20 (24)	54.0mm	500mm	39.5mm	789	Meter
LXHIOZ1-1X58.0	12/20 (24)	59.0mm	630mm	44.0mm	930	Meter
LXHIOZ1-1X41.5	18/30 (36)	41.5mm	70mm	27.5mm	234	Meter
LXHIOZ1-1X46.5	18/30 (36)	46.5mm	150mm	32.0mm	373	Meter
LXHIOZ1-1X47.5	18/30 (36)	48.0mm	185mm	33.5mm	427	Meter
LXHIOZ1-1X50.5	18/30 (36)	50.5mm	240mm	36.0mm	504	Meter
LXHIOZ1-1X56.5	18/30 (36)	56.5mm	400mm	41.5mm	681	Meter
LXHIOZ1-1X60.0	18/30 (36)	59.5mm	500mm	44.5mm	792	Meter
LXHIOZ1-1X63.5	18/30 (36)	64.5mm	630mm	49.0mm	933	Meter

Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas


FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock,
it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: 30% T/T in advance,70% T/T balance before shipment
