- Model NO.:HV ABC Cable
- Range of Application:Distribution
- Certification:ISO9001, CCC
- Brand:Boan
- Rated Voltage:6.35,11 Kv
- Number of Cores:3+1
- Size:35-185 Mm2
- Class of Conductor:2
- Transport Package:Heated Steel-Wooden Drum,Steel Drum
- Specification:SGS
- Trademark:DingAn
- Origin:Jiangsu Yixing, China
- HS Code:8544601200
- Production Capacity:12000 Km,Year
AS/NZS-3599.2 |
| Units | 6.35/11 KV |
Nominal Conductor Area | mm2 | 35 | 50 | 70 | 95 | 120 | 150 | 185 |
Average Insulation Thickness | mm | 3.4 | 3.4 | 3.4 | 3.4 | 3.4 | 3.4 | 3.4 |
Average Insulation Screen Thickness | mm | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 |
AAAC/1120 Support Conductor Size | no/mm | 7/4.75 | 7/4.75 | 7/4.75 | 7/4.75 | 19/3.50 | 19/3.50 | 19/3.50 |
Nominal Overall Diameter | mm | 48.4 | 50.7 | 53.9 | 57.3 | 63.3 | 66.2 | 69.2 |
Approx. Mass | kg/km | 1170 | 1320 | 1560 | 1860 | 2280 | 2570 | 2890 |
DC Resistance at 20°C | Ω/km | 0.868 | 0.641 | 0.443 | 0.320 | 0.253 | 0.206 | 0.164 |
AAAC/1120 Support Conductors | | | | | |
| Units | | | | | | | |
Stranding & Nom. Wire Dia. | no/mm | 7/4.75 | 19/3.50 | | | | | |
Nominal Overall Diameter | mm | 14.3 | 17.5 | | | | | |
DC Resistance at 20°C | Ω/km | 0.239 | 0.163 | | | | | |
Minimum Breaking Load | kN | 27.1 | 41.7 | | | | | |
