LV Mv Hv XLPE Insulated Power Cable

YIFANG ELECTRIC GROUP INC.
  • Voltage：Low and Medium Voltage Cable
  • Current：AC Cable
  • Insulation Material：XLPE
  • Sheath Material：PVC
  • Material Shape：Round Wire
  • Wire Core Material：Red Copper Wire

Base Info

  • Model NO.：xlpe insulated power cable
  • Certification：ISO, CCC, CE, RoHS, UL, VDE
  • Transport Package：Wooden Drum, Wooden Iron Drum, Steel Drum, etc
  • Specification：GB, IEC, BS, ASTM, etc.
  • Trademark：Yifang
  • Origin：China
  • HS Code：8544464120
  • Production Capacity：500, 000km Per Month

Description

YJVCopper Conductor, XLPE Insulated, PVC Sheathed Power CableFor laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.YJLVAl. Conductor, XLPE Insulated, PVC Sheathed Power CableYJYCopper Conductor, XLPE Insulated, PE Sheathed Power CableFor laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.YJLYAl. Conductor, XLPE Insulated, PE Sheathed Power CableYJV22XLPE Insulated,Steel Tape Armored,PVC Sheathed Power CableSuitable for burying in ground, Able to bear external mechanical forces but large pulling forces.YJLV22Al. Insulated,Steel Tape Armored,PVC Sheathed Power CableYJV32Copper Conductor, XLPE Insulated, Fine Steel Wire Armored,PVC Sheathed Power CableApply to shafts,water and soil,able to bear the larger positive pressure.YJLV32Al.Conductor, XLPE Insulated, Fine Steel Wire Armored,PVC Sheathed Power CableYJV42Copper Conductor, XLPE Insulated,Thick Steel Wire Armored,PVC Sheathed Power CableFor laying in shaft, water underground and large diference of level, able to bear external mechanical pressure and moderate pulling force.YJLV42Al.Conductor, XLPE Insulated,Thick Steel Wire Armored,PVC Sheathed Power Cable

Technical data

Rated voltage: 0.6/1kV, 1.8/3kV, 6/10kV, 8.7/10kV, 8.7/15kV, 12/20kV, 18/30kV, 21/35kV, 26/35kV
Maximum Conductor Temperature: under normal (90°C), emergency (130°C) or short circuit no more than 5 s (250°C) conditions.
Min. Ambient Temp. 0°C, after installation and only when cable is in a fixed position
Min. Bending Radius: 20 x cable O.D for single-core non-armoured cables
                                15 x cable O.D for single-core armoured cables
                                15 x cable O.D for multi-core non-armoured cables
                                12 x cable O.D for multi-core armoured cables
