Superfine Nichrome wire Ni80Cr20 0.03mm 0.04mm 0.05mm 0.06mm wire

Shanghai Tankii Alloy Material Co., Ltd.
  • Type：Bare
  • Conductor Type：Solid
  • Application：Heating
  • Conductor Material：Nickel Alloy
  • Insulation Material：Fiberglass
  • Certification：ISO9001, RoHS

Base Info

  • Model NO.：Ni80Cr20
  • Brand：Tankii
  • Surface：Bright, Shinning, No Oil
  • Stock size：0.03mm~0.071mm
  • MOQ：1kg
  • Package：Carton box
  • Transport Package：Spool, Carton, Wooden Case
  • Specification：0.5mm
  • Trademark：TANKII
  • Origin：China
  • HS Code：7505220000
  • Production Capacity：100 Tons,Year

Description

Chemical Composition and Main Properties of NichromeProperties GradeNi80Cr20Ni70Cr30Ni60Cr15Ni35Cr20Ni30Cr20Main Chemical CompositionNiBalanceBalance55.0-61.034.0-37.030.0-34.0Cr20.0-23.028.0-31.015.0-18.018.0-21.018.0-21.0Fe≤ 1.0≤ 1.0BalanceBalanceBalanceMax Continuous Service Temperature(oC)12001250115011001100Resisivity 20oC  (Ω mm2/m)1.091.181.121.041.04Density (g/cm3)8.48.18.27.97.9Thermal Conductivity(KJ/m@ h@ oC)60.345.245.243.843.8Coefficient of Thermal Expansion(α × 10-6/oC)1817171919Melting Point( oC)14001380139013901390Elongation(%)> 20> 20> 20> 20> 20Micrographic StructureausteniteausteniteausteniteausteniteausteniteMagnetic PropertynonmagneticnonmagneticnonmagneticWeak magneticWeak magneticSuperfine Nichrome wire Ni80Cr20 0.03mm 0.04mm 0.05mm 0.06mm wire
