S 90 Cable Continuously Flexible PUR Continuous Flex Control Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：S 90 Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, CCC, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemS 90 Cable Continuously Flexible PUR Continuous Flex Control Cable ConductorBare copper stranded condutorInsulationPVCStrandingSpecially adjusted layering with non-woven tape over each layerWrappingNon-woven tapeOuter sheathPUR, TMPU acc. to EN 50363-10-2 + VDE 0207-363-10-2 with mat surfaceCore numberMulticores (As client's requirement)Nominal voltageUo/U 300/500 VTesting voltage core/core 3000 VMin. bending radius fixed Continuously flexible: 7,5 x dTemperature range

Fixed laying: -40/+70°C

Flexible application: +5/+70°C

Fire performanceFlame retardant and self-extinguishing acc. to IEC 60332-1-2 + VDE 0482-332-1-2ApplicationContinuous flex control cable with numbered cores as well as high tear resistance. The acid-resistant flexible control cable with increased efficiency due to the permanent use with millions of bending cycles is recommended for use in handling, material handling and automation technologies, wood working and packaging machines, welding machine and cutting systems.
