RoHS Approved UL1032 Copper Conductor PVC Coated Wire 1000V Voltage Eletrical Wire Cable
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：for General Purpose Internal Wiring of Appliance
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：UL1032
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, Reach
- Brand：B&T
- Rated Temperature：90 ºC
- Rated Voltage：1000V
- According to：UL Subject758, UL1581, C22.2
- Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
- Performance：for General Purpose Internal Wiring of Appliance
- Conductor：Stranded, Tinned or Bare Copper Conductor
- AWG/No.Ofcond：32-16AWG
- Color：Could Be Customized Color
- Products Certification：UL,cUL,RoHS, Reach
- Factory Certificate：ISO9001:2008 Standard
- Transport Package：610 Feet in Roll
- Specification：26-4AWG
- Trademark：B&T
- Origin：Xiamen, Fujian
- HS Code：8544492100
- Production Capacity：300, 000km
Description
Maximum Resistance at 20ºC
Ω/kmAWG No./mm Dia.
mm Nom. Thick.
mm Nom.Dia.
mm 26 7/0.16 0.48 0.80 2.08 139 24 11/0.16 0.61 0.80 2.20 88.9 22 17/0.16 0.76 0.80 2.36 57.5 20 26/0.16 0.94 0.80 2.54 34.6 18 41/0.16 1.18 0.80 2.78 23.3 16 26/0.254 1.49 0.80 3.10 15.1 14 41/0.254 1.87 0.90 3.70 9.2 12 65/0.254 2.36 1.02 4.40 5.4 10 65/0.32 2.97 1.02 5.00 4.1 8 7/37/0.20 4.20 1.20 6.60 2.23 6 19/7/0.36 5.40 1.60 8.60 1.4 4 7/18/0.46 6.72 1.60 9.90 0.882
Ω/km
mm
mm
mm
