• Model NO.：Twin
• Material Shape：Twisted
• Certification：ISO9001, CE, CCC
• Brand：Yifang
• Product Name：Twisted Conductor Twin AAC ACSR AAAC Vibration
• Transport Package：Wooden Drum, Steel Drum, Wooden&Steel Drum
• Specification：up to 1500mm2
• Trademark：YIFANG
• Origin：Zhengzhou China
• HS Code：7614900000
• Production Capacity：1000 Ton,Month

Basic Info.

Model NO. Twin Material Shape Twisted Certification ISO9001, CE, CCC Brand Yifang Product Name Twisted Conductor Twin AAC ACSR AAAC Vibration Transport Package Wooden Drum, Steel Drum, Wooden&Steel Drum Specification up to 1500mm2 Trademark YIFANG Origin Zhengzhou China HS Code 7614900000 Production Capacity 1000 Ton/Month

Product Description

APPLICATIONS
Twisted conductor, a vibration-resistant, bare aluminum construction, is designed for use in overhead applications subject to Aeolian vibration and galloping due to wind and ice.
Twisted conductor can be strung to the maximum allowable tension limits without the need for additional vibration protection.
SPECIFICATIONS
Twisted conductor meets or exceeds the following ASTM specifications for the sub conductor of each conductor assembly:
B-231 Aluminum Conductor, Concentric-Lay-Stranded
B-232 Aluminum Conductor, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR).
B-778 Shaped Wire Compact Concentric-Lay-Stranded Aluminum Conductors (AAC/TW)
B-779 Shaped Wire Compact Concentric-Lay-Stranded Aluminum Conductors, Steel Reinforced (ACSR/TW)
CONSTRUCTION
Twisted conductor is composed of two identical bare conductors twisted together with a left hand lay. This gives the cable a figure 8 spiral shape. This spiral shape disrupts the forces created by steady cross winds which cause cable vibration by presenting a continuously changing projected cable diameter to the wind. This spiral shape, together with less torsional stiffness and varying bending stiffness also reduces or eliminates cable galloping due to combined ice and wind. Twisted conductor is engineered with a lay length that changes with conductor diameter. The engineered lay ensures that the product will install without bagging issues while still providing equal or better resistance to Aeolian vibration and ice galloping. The component conductors of Twisted conductor can be conductor types AAC, ACSR, AAC/TW, or ACSR/TW meeting the requirements of the appropriate ASTM standard. Other sizes available upon request.
