Thw Stranded Electrical Wire 14AWG 12AWG 10AWG 8AWG
Henan Hongda Cable Co., Ltd.- Type：Insulated
- Conductor Type：Solid or Stranded
- Application：Building or House
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：THW stranded electrical wire
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CCC
- Brand：Hongda
- Color：Red Blue Black Yellow Green White
- Transport Package：in Coil or in Pallent
- Specification：14 12 10 8 6 4 2 1
- Trademark：hongda
- Origin：Henan
- HS Code：8544492100
- Production Capacity：10000m,Day
Description
Nominal Insulation
Thichness Inch/mm Nominal Overall
Diameter Inch/mm Cable Weight
Lbs/kft kg/km 14 1 0.030 0.76 0.169 4.3 22 33 12 1 0.030 0.76 0.189 4.8 32 47 10 1 0.030 0.76 0.213 5.4 46 68 8 1 0.045 1.14 0.240 6.1 67 100 14 7 0.030 0.76 0.177 7 101 151 12 7 0.030 0.76 0.201 4.5 24 36 10 7 0.030 0.76 0.228 5.1 34 50 8 7 0.045 1.14 0.291 5.8 49 73 6 7 0.060 1.52 0.335 7.4 79 118 4 7 0.060 1.52 0.386 8.5 117 174 2 7 0.080 2.03 0.445 9.8 172 256 1 19 0.080 2.03 0.531 11.3 263 391 1/0 19 0.080 2.03 0.575 13.5 339 505 2/0 19 0.080 2.03 0.622 14.6 418 622 3/0 19 0.080 2.03 0.677 15.8 515 767 4/0 37 0.080 2.03 0.740 17.2 638 950 250 37 0.095 2.41 0.823 18.8 792 1179 300 37 0.095 2.41 0.882 20.9 943 1404 350 37 0.095 2.41 0.937 22.4 1118 1664 400 37 0.095 2.41 0.984 23.8 1292 1923 500 61 0.095 2.41 1.079 25 1465 2180 600 61 0.110 2.79 1.197 27.4 1810 2694
Thichness Inch/mm
Diameter Inch/mm
Lbs/kft kg/km
