China Cable 5 Core Yjv XLPE Power Cable with Best Service
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial, Power Station, Telecommunication, China Cable 5 Core Yjv XLPE Power Cable with Best
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：IEC 60502-1
- Wire Core Material：Steel
- Certification：ISO, CCC, CE
- Model：YJV
- Brand：Henan Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：5
- Cross Section：185mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：90°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：18,30kv
- Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Warranty：One Year
- Transport Package：by Sea
- Specification：China cable 5 core yjv xlpe power cable with best
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：5000
Description
YJV CU/XLPE/PVC
YJLV
AL/XLPE/PVCmm2 mm mm mm mm kg/km kg/km A A A A 5×1.5 RE 1.38 0.7 1.8 11.7 184.3 137.7 21 - 26 - 5×2.5 RE 1.78 0.7 1.8 12.8 242.3 164.6 28 21 35 26 5×4 RE 2.24 0.7 1.8 14.1 324.9 200.6 40 30 55 45 5×6 RE 2.76 0.7 1.8 15.4 446.3 259.8 50 40 65 55 5×10 CC 3.8 0.7 1.8 18.2 664.2 353.3 70 55 90 70 5×16 CC 4.8 0.7 1.8 20.9 965.5 468.1 90 70 110 90 5×25 CC 6.0 0.9 1.8 25.3 1456.5 679.2 130 105 150 120 5×35 CC 7.0 0.9 1.8 28.0 1939.4 851.3 165 130 185 140 5×50 CC 8.4 1.0 2.0 32.1 2649.3 1094.9 200 160 210 170 5×70 CC 10.0 1.1 2.1 37.1 3645.3 1469.0 285 203 265 203 5×95 CC 11.5 1.1 2.3 41.6 4846.2 1892.7 320 255 315 250 5×120 CC 13.0 1.2 2.4 46.4 6074.4 2343.6 380 300 360 285 5×150 CC 14.5 1.4 2.6 51.9 7589.3 2925.8 440 350 400 320 5×185 CC 16.2 1.6 2.8 56.0 9342.3 3590.7 505 490 435 350 5×240 CC 18.4 1.7 3.0 64.9 12016.7 4555.2 603 471 524 415 5×300 CC 20.5 1.8 3.2 71.5 14918.0 5591.1 700 545 605 465
China cable 5 core yjv xlpe power cable with best serviceChina cable 5 core yjv xlpe power cable with best serviceChina cable 5 core yjv xlpe power cable with best service
YJLV
AL/XLPE/PVC
