Aluminum Phase Core ACSR Bare Messenger Duplex Service Drop Cable

YIFANG ELECTRIC GROUP INC.
  • Application：Overhead
  • Voltage：600,1000V
  • Current：AC Cable
  • Insulation Material：XLPE PE
  • Material Shape：Round Wire
  • Wire Core Material：Aluminum ACSR

Base Info

  • Model NO.：ABC BL22
  • Certification：ISO, CCC, CE
  • Brand：Yifang
  • Color：Black
  • Conductor：Compacted Stranded Harn Drawn Wire
  • Insulation：Weather, UV Proof XLPE PE
  • Transport Package：Standard Export Wooden Drum
  • Trademark：Yifang
  • Origin：Zhengzhou City, Henan Province, China
  • HS Code：8544492100
  • Production Capacity：500 Kilometers,Month

Description

Nominal csetion area(sqmm)Conductor structureInsulation materialInsulation Thickness(mm)Approx. Overall Diameter(mm)Approx. weight
(kg/km)Packing meters per drumPhase
(Compacted AL)Neutral
(bare ACSR)(No./mm)Aluminum
(No./mm)Steel
(No./mm)1x16+167/1.726/1.721/1.72XLPE1.212.5121.9250-4000m1x25+257/2.156/2.151/2.15XLPE1.214.9182.2250-40001x35+357/2.546/2.541/2.54XLPE1.417.5254.7250-3500m1x70+7019/2.1512/2.157/2.15XLPE1.423.6382.2250-3000m1x95+9519/2.5412/2.547/2.54XLPE1.627.6528.2250-3000m2x16+167/1.726/1.721/1.72 *1.214.2187.6250-4000m2x25+257/2.156/2.151/2.15 *1.216.7273.8250-3500m3*35+357/2.54XLPE
6/2.541/2.54 *1.419.7386.9250-3500m2x70+7019/2.1512/2.157/2.15 *1.426.1617.2250-3000m2x95+9519/2.5412/2.547/2.54 *1.630.5850.9250-3500m3x70+7019/2.1512/2.157/2.15 *1.429.71024.3250-3000m3x95+9519/2.5412/2.547/2.54 *1.634.61413.7250-3000m
