• Model NO.：TOP-GPS04
• Brand：Top
• Connector：SMA,SMB,MCX,MMCX etc
• Cable：Rg174
• Transport Package：1PCS,Carton
• Specification：CE, ROHS
• Trademark：TOP
• Origin：Shen Zhen
• HS Code：8517707090
• Production Capacity：500000PCS,Year

Basic Info.

Model NO. TOP-GPS04 Brand Top Connector SMA,SMB,MCX,MMCX etc Cable Rg174 Transport Package 1PCS/Carton Specification CE, ROHS Trademark TOP Origin Shen Zhen HS Code 8517707090 Production Capacity 500000PCS/Year

Product Description

Product Description

GPS Antenna

Dieletric Antenna

Center Frequency 1575.42 MHz± 3 MHz

V. S. W. R 1.5: 1

Band Width ± 5 MHz

Impendence 50 ohm

Polarization Type RHCP

LNA / Filter

LNA Gain(Without cable) 28± 2 dB Typical

Noise Figure 1.5 dB

DC Voltage 2.2~5 V

DC current 5~15 mA

Mechanical

Cable RG174 5m / 3m / or others

Connector SMA / SMB / MCX / or others

Housing Black or others

Environmental

Working Temp -40 c~+85 c

Humidity 55%~75%RH

Waterproof IP67



Our  Antenna :
---Powerful R&D team ---Wonderful design solution
---Perfect after-sales service
---Strict quality testing
---Rich cooperation experiences with Communication product manufactures
---Competitive price


FAQ
 1. What's the Warranty of the Products?
Answer: In general, all goods with 12 month-warranty after the shipments .

2.  How about the defective rate ?
Answer: Less than 1%.

 3. Where can customers get the Product Specification and other datasheets?
Answer: we will send them via email once get the request from the customers.

 Our high quality products , competitive  price and professional service, be sure to meet your need for all kinds of components.    ^_^





Packing & Shipping


TOP Electronic is specializing in LTE/3G/GPS/GPRS modules, LTE/3G/GPS/GPRS antennas, Electronic components  etc.
We're one of the biggest stocking distributors of communication products and active electronic components located in Shenzhen,
module brands include Sierra, Simcom, Cinterion, Huawei, Holux, Globalsat, GlobaTop, Skylab, Telit, U-blox etc.
You'll obtained best price and after-sales support with stable stock from us always.
