UL Standard 200c High Temperature Silicone Electric Cable UL3135
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Lighting, Lamb
- Conductor Material：Copper
- Insulation Material：Silicone Rubber
- Material Shape：Round Wire
Base Info
- Model NO.：UL3135
- Range of Application：Flame Retardant
- Certification：UL, RoHS, Reach
- Brand：Bort
- Packaging：1000FT,Spool
- Weight：About 1kg,1000FT
- Color Available：Any Colors
- Delivery Time for Samples：3-5days
- Delivery Time for Mass Production：7-10days
- Appliance：Heating Source for Lighting, Auto Ignition
- Warranty Time：at Least 10years for Proper Use
- Standard of Production：RoHS & Reach
- Factory Management Standard：ISO9001:2008
- Annual Capacity：300,000kms
- Transport Package：Coiled in The Plastic Spool
- Specification：20AWG
- Trademark：BoRt
- Origin：Zhangzhou, China
- HS Code：8544492900
- Production Capacity：300000kms
Description
AWGCONSTRUCTION Diameter Thickness Diameter NO./mm mm mm mm Ω/KM 26 7/0.16 0.48 0.78 2.05 150.00 24 7/0.20 0.61 0.78 2.15 94.20 22 7/0.254 0.76 0.78 2.32 59.40 20 7/0.30 0.92 0.78 2.48 36.70 20 21/0.18 0.95 0.78 2.51 36.70 18 7/0.39 1.19 0.78 2.75 23.20 18 30/0.18 1.19 0.78 2.70 23.20 16 7/0.49 1.50 0.78 3.06 14.60 16 50/0.18 1.50 0.78 3.06 14.6 14 41/0.254 1.90 0.78 3.46 8.96 12 65/0.254 2.36 0.78 3.95 5.64
