U/FTP CAT6A Made in China High Quality, Ce, RoHS, ISO, ETL, CPR Cable

Hangzhou Risun Cable Co., Ltd.
  • Application：Local Communication Cable, LAN Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：LSZH
  • Type：CAT6A
  • Material Shape：Round Wire
  • Conductor Type：Solid

Base Info

  • Model NO.：U,FTP CAT6A
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS, ETL, CPR
  • Model：LAN Cable CAT6A
  • Brand：Risun
  • Conductor：23AWG
  • Insulation：1,35mm Foam PE
  • Shield：Each Pair Aluminum Foil
  • Drain：Tc
  • Sheath：LSZH
  • Transport Package：305m
  • Specification：23AWG
  • Trademark：RISUN or OEM
  • Origin：Zhejiang, China
  • HS Code：8544491100
  • Production Capacity：20000 Boxes,Month

Description

U/FTP CAT6A Made in China High Quality, Ce, RoHS, ISO, ETL, CPR CableDESCRIPTION

Manufactured according to ISO / IEC 11801-2, ISO / IEC 64156-5, EIA / TIA 568B, EN 60332-1-2 Flame propagation

         TECHNICAL SPECIFICATIONS   Conductor Bare copper0.57±0.01 mmU/FTP CAT6A Made in China High Quality, Ce, RoHS, ISO, ETL, CPR Cable

 Insulation Foam PE 1.35±0.05 mmIdentification of pairs   1 pairBlue - White / Blue 2 pairOrange - White / Orange 3 pairGreen - White / Green 4 pairBrown - White / BrownShieldeach pair foiledRipcordYesSheathLSZHColorBlueBending radius≥ 8 x Diameter (mm) InstallationStorage temperature-15ºC-+70ºC         ELECTRICAL CHARACTERISTICS

Reaction to fireDca-s2, d2, a1         ApplianceCable for data transmission in structured cabling networks (LAN), horizontal and secondary facilities.         Packing

  • All sizes and values without tolerances are reference values. We reserves the right to amend this specification without prior notice.
