Xlfmkk Cable 250V Thermoplastic Insulated and Sheathed Shield Light Marine Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Special Thermoplastic
  • Insulation Material：Special Thermoplastic
  • Material Shape：Round Wire

Base Info

  • Model NO.：XLFMKK Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemXLFMKK Cable 250V Thermoplastic Insulated and Sheathed Shield Light Marine Cable  ConductorCopper wire bareInsulationSpecial thermoplasticCover layerHigh-strength polyamide sheathInner sheathSpecial thermoplastic sheath material ShieldIndividually shield and overall shield are braided with copper wire, coverage rate 80%Outer sheathSpecial thermoplastic sheathCore NumberMulticores (As client's requirement)Peak operating voltageUo/U 250 V Test Voltage1200 VTemperature-10 ºC ~ + 85 ºCColorOptionalApplicationThe cable is flexible, weather-resistant, and corrosion-resistant. It is suitable for fixed installation on the hull where it is no subject to mechanical stress, such as various water buildings such as rivers and seas, and offshore oil platforms.
