S type tc wire used for thermocouple sensor
Shanghai Tankii Alloy Material Co., Ltd.- Type：Bare
- Conductor Type：Solid
- Application：Thermocouple sensor
- Conductor Material：Platinum-Rhodium
- Sheath Material：NON
- Insulation Material：Non
Base Info
- Model NO.：S
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, RoHS
- Brand：Tankii
- Name：S type B type R type tc wire used for thermocouple
- Dia：0.03-0.5mm
- Surface：Bright
- Grade：I,II
- Shape：wire, rod, sheet
- Insulation：Avaiable
- Standard：IEC,ANSI, DIN
- Leading time：3~5 days
- Package：Export package
- Transport Package：Spool, Carton, Wooden Case
- Specification：0.03-0.5mm
- Trademark：TANKII
- Origin：China
- HS Code：7506200000
- Production Capacity：1000 Ton Per Year
Description
Chemical CompositionConductor Name Polarity Code Nominal Chemical Composition /% Pt Rh Pt90Rh Positive SP 90 10 Pt Negative SN,RN 100 -- Pt87Rh Positive RP 87 13 Pt70Rh Positive BP 70 30 Pt94Rh Negative BN 94 6 Dia. /mm Type Long time working temp./ ºC Short time working temp. / ºC 0.5 S 1300 1600 0.5 R 1300 1600 0.5 B 1600 1700
