RG6 Low Loss Coaxial Cable for TV/CATV/Satellite/Antenna/CCTV
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：RG6
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS
- Brand：OEM
- Conductor Size：1.02
- Braiding：32,48,64,96,112,128,144
- Transport Package：200m,300m,305m
- Specification：0.8mm Conductor
- Origin：China
- HS Code：8544200000
- Production Capacity：4000km,Month
Description
Basic Info.
Model NO. RG6 Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS Brand OEM Conductor Size 1.02 Braiding 32/48/64/96/112/128/144 Transport Package 200m/300m/305m Specification 0.8mm Conductor Origin China HS Code 8544200000 Production Capacity 4000km/MonthProduct Description
Applications
Suitable for CCTV/security-camera use where power feed is required for the camera and/or pan/tilt mechanism, surveillance and CCTV plus audio or pan and tilt CCTV control
Standards
SCTE IPS-SP-001 UL1655 UL13 UL444 TFC drop cable IEEEC
Specifications
Technical:
Conductor material: 1.02mm CCS (18%)
Insulation material: 4.57mm FPE
Shielding: bonded Al-foil
Braiding: 64*0.12mm Al-Mg braiding wires
Jacket material: 6.91mm PVC OEM services
Optional
1) Inner conductor: tinned copper, bare copper, copper clad steel available
2) Al-foil: Al-foil, bonded Al-foil, double bonded Al-foil and APA available
3) Braiding wire: AL-Mg, bare copper and tinned copper available
4) Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available
5) Braiding coverage: 30- 95% available
6) Jacket colors: white, black, transparent
Compliant
Electrical characteristics:
Nominal impedance: 75 ±3 ohms
Nominal velocity of propagation: 80%
Nominal capacitance: 16.2PF/ft
DC resistance inner conductor: ≤33 ohms/km
DC resistance: 18AWG strand ≤22 ohms/km
Return loss at : 5-1002MHz ≥22dB
| Type | |
|---|---|
| Conductor Material | Copper clad steel |
| The diameter of the conductor, mm | 0.75/0.8/0.9/1.0/1.02 |
| The material of the dielectric | Foamed PE |
| Diameter Dielectric, mm | 4.57 ± 0.15 |
| Type of foil | Al-Tape bonded |
| The number of layers | 2 |
| Braid Material | AL-MG |
| Surface braid,% | 32X0.12 |
| Jacket wall thickness | 0.76 ± 0.15 |
| The Jacket material | PVC |
| Diameter of shell, mm | 6.6 ± 0.2 |
| Color | Black or white |
| TECHNOLOGY DATA | |
|---|---|
| Characteristic Impedance | 75±3Ohm |
| Capacitance | 52±1pF/m |
| Velocity | >82% |
| Conductor & Dielectric To stick (kgt/m 1m/min) | 2.55kgf (10.2kgf/m) |
| Insulation resistance | 1000MOhm(20ºC) |
| Frequence (at 20ºC) | Max.Attenuation |
| 5MHz | 1.90dB/100m |
| 55MHz | 5.30dB/100m |
| 211MHz | 10.0dB/100m |
| 270MHz | 11.0dB/100m |
| 300MHz | 11.60dB/100m |
| 330MHz | 12.30dB/100m |
| 400MHz | 13.60dB/100m |
| 450MHz | 14.40dB/100m |
| 550MHz | 16.20dB/100m |
| 750MHz | 19.00dB/100m |
| 870MHz | 20.60dB/100m |
| 1000MHz | 21.49dB/100m |
