Single-Mode FC/APC-FC/APC 9/125um Optical Fiber Cable
Shenzhen Shengmeida Communication Co., Ltd.- Application：Communication, Art, Medicine, Probe, CATV LAN
- Type：Single-mode Fiber
- Connection Structure：FC-FC
- Material Shape：Round Wire
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：100N<1000N
Base Info
- Model NO.：FC,APC-FC,APC
- Core：Single Core
- Certification：RoHS
- Sheath Material：LSZH, PVC and Ofnr Are Available
- Operating Temperature：-40~75
- Durability：>1000 Matings
- Transport Package：Carton
- Specification：0.9,2.0,3.0mm
- Trademark：SMD
- Origin：China
- HS Code：8544700000
- Production Capacity：200000,Month
Description
Basic Info.
Model NO. FC/APC-FC/APC Core Single Core Certification RoHS Sheath Material LSZH, PVC and Ofnr Are Available Operating Temperature -40~75 Durability >1000 Matings Transport Package Carton Specification 0.9/2.0/3.0mm Trademark SMD Origin China HS Code 8544700000 Production Capacity 200000/MonthProduct Description
Single-mode FC/APC-FC/APC 9/125um Optical Fiber CableType FC/APC-FC/APC Singlemode SM Fiber Patch Cord Connector. SC FC LC ST optical fiber connector is the two end precision optical fiber optic jumper, dock up according to the transmission medium can be divided into common silicon-based optical single-mode, multi-mode jumpers, and other such as plastic for transmission medium of fiber optic jumper cables, By connecting head structure forms can be divided into: FC , SC,ST , LC , MTRJ , MPO, MU, SMA , FDDI , E2000 , DIN4 , D4 etc various forms.
Product Description of fiber jumper
| model | FC/APC-FC/APC | Mating cycles | >1000 |
| length | 3M | Operating temperature | -40ºC-85ºC |
| Insertion Loss | ≤0.3dB | Tensile strength | ≥100N |
| mode | simplemode | wavelength | 1310nm or 1550nm |
| weight | 30piece/KG | outer diameter | 3.0mm(oem2.0mm,0.9mm) |
Features
Price-Competitive
Low Insertion Loss & PDL
Factory-terminated and Tested
Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber
Applications
CATV
Active device termination
Telecommunication networks
Metro
Local Area Networks (LANs)
Data processing networks
