11kv Aluminum Secondary Distribution Quadruplex Service Drop 3*70+1*70 ABC Self-Sustaining Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Industrial, Public Power Distribution Network 12,20 Kv
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：XLPE
- Sheath Material：PE, HDPE, LDPE, LLDPE
- Material Shape：Round Wire
Base Info
- Model NO.：JKLYJ
- Wire Core Material：Aluminum
- Certification：ISO, CCC, SGS
- Model：Al,XLPE,HDPE
- Brand：Hongda
- Rated Voltage：11kv
- Test Voltage：45 Kv,50 Hz
- Bending Radius (Min.)：18 X D of Cable
- Transport Package：Steel & Wooden Drum
- Specification：16sqmm to 240sqmm
- Trademark：Hongda Cable
- Origin：Made in China
- HS Code：8544601200
- Production Capacity：300km,Month
Description
Application:
NF C 33-226 cables are the new generation of cables for public power distribution network 12/20 kV.
The cable can be used for overhead power transmission . The cable can bear external mechanical pressure and moderate pulling force with different design , such as metallic armour , water proof material , etc.
Standard
NF C 33 226
11kv aluminum Secondary distribution Quadruplex Service drop 3*70+1*70 ABC Self-sustaining cable Specifications:Dimensions
OPTIONS
NF C 33-226 cables can be manufactured with the following options:
- Copper conductor
- Other voltage
- Other section
- Grounding conductor
- Thicker aluminium screen
- Bunch
- Re-enforced burying resistance (EDR) is ensured with an extruded polyethylene protection.
Packing shipping
Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Shipping Port:
Shanghai, Qingdao, Tianjin or other ports as per your requirements.
Sea freight:
FOB/C&F/CIF/DAP quotation are all available.
