• Model NO.：Alarm Cable
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS, ETL SGS CPR
• Model：Alarm Cable
• Brand：Risun or OEM
• Color：as Your Request
• Transport Package：100, 200, 500m,Roll or Wooden Reel
• Specification：CE, ISO9001, RoHS, ETL, SGS
• Trademark：RISUN or OEM
• Origin：Hangzhou, China(Mainland)
• HS Code：8544491100
• Production Capacity：20000box,Month

Conductor7/0.20mm±0.01mm, 0.22mm² TC/BC/CCAInsulationFrame retardant PVCCores2-20Drain Wire24AWG Bare Copper/ Tinned CopperShieldPolyester Tape + Aluminum FoilSheathDia according to cores. Frame Retardant PVC

Packing:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's request;

Usage:                 Securitity alarm

Certificate:        CE, RoHS, ETL, SGS



                                                                                                                                      0.20mm² Conductor Shielded

No.of cores*No/Nominal Diameter     (mm)	Insulation Thickness (mm)	Nom.O.D (mm)	Weight (Kg/Km)
2*1/0.50	0.25	3.5±0.2	14.1±0.5
4*1/0.50	0.25	4.1±0.2	17.38±0.5
6*1/0.50	0.25	4.6±0.2	27.8±0.5
8*1/0.50	0.25	5.3±0.2	34.4±0.5
10*1/0.50	0.25	5.8±0.2	40.5±0.5
12*1/0.50	0.25	6.5±0.2	49.5±0.5
16*1/0.50	0.25	7.3±0.2	59.8±0.5
20*1/0.50	0.25	8.4±0.2	72.5±0.5

                                                                                                                                     0.20mm² Conductor Shielded

No.of cores*No/Nominal Diameter     (mm)	Insulation Thickness (mm)	Nom.O.D (mm)	Weight (Kg/Km)
2*7/0.20	0.25	3.5±0.2	14.6±0.5
4*7/0.20	0.25	4.1±0.2	18.3±0.5
6*7/0.20	0.25	4.6±0.2	28.4±0.5
8*7/0.20	0.25	5.3±0.2	35.8±0.5
10*7/0.20	0.25	5.8±0.2	42.6±0.5
12*7/0.20	0.25	6.6±0.2	50.5±0.5
16*7/0.20	0.25	7.5±0.2	63.8±0.5
20*7/0.20	0.25	8.7±0.2	76.7±0.5

The specification, packing, pringting brand all according to customer.
