• Model NO.：UPB
• Installation Situat：Wooden, Metal or Concrete Poles.
• Transport Package：Wooden Case
• Specification：CE, RoHS, SGS, ISO
• Trademark：POWTECH
• Origin：China
• Production Capacity：50000PCS,Month

Basic Info.

Model NO. UPB Installation Situat Wooden, Metal or Concrete Poles. Transport Package Wooden Case Specification CE, RoHS, SGS, ISO Trademark POWTECH Origin China Production Capacity 50000PCS/Month

Product Description

 Aluminium alloy UPB bracket



Detailed Images:

The UPB bracket is manufactured from aluminum alloy with correspondingly high mechanical strength. Its unique  patented design has been developed to propose a universal fitting covering all installation situations on wooden, metal or concrete poles.

Model	Materials	Working Load	Weight
UPB	Aluminum Alloy	5000N	0.2kg

Application:

With steel bands

The UPB bracket can be installed on any type of pole - drilled or undrilled - with two 20x0.7 mm stainless steel bands plus two buckles . Usually allow two bands of one meter each per bracket.

With bolts

If the top of the pole is drilled (wooden poles, occasionally concrete poles) the UPB bracket can also be secured with a 14 or 16 mm bolt. The bolt length should be at least equal to the pole diameter + 50 mm (bracket thickness).
