0.711mm KX thermocouple cable 22SWG quartz fiber insulation 1000C
Shanghai Tankii Alloy Material Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Heating, Thermocouple sensor
- Conductor Material：Chromel Alumel
- Sheath Material：fiberglass
- Insulation Material：Fiberglass
Base Info
- Model NO.：K
- Material Shape：Round Wire
- Range of Application：Thermocouple sensor
- Certification：ISO9001, RoHS
- Brand：Tankii
- Item：0.711mm KX thermocouple cable 22SWG quartz fiber i
- Wire Surface：Insulated
- Grade：I,II,III
- Standard：GB,IEC,ANSI
- Shape：wire, ribbon, strip, rod
- RoHS：Yes
- MTC：Yes
- SGS：Yes
- Leading time：5-7 days
- Package：Bobbin, carton box, wooden box
- Transport Package：Spool, Carton, Wooden Case
- Specification：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mm
- Trademark：TANKII
- Origin：China
- HS Code：75052200
- Production Capacity：5000 Tons,Year
Description
Thermocouple Code
Comp. Type
Comp. Wire Name
Positive
Negative
Name
Code
Name
Code
S
SC
copper-constantan 0.6
copper
SPC
constantan 0.6
SNC
R
RC
copper-constantan 0.6
copper
RPC
constantan 0.6
RNC
K
KCA
Iron-constantan22
Iron
KPCA
constantan22
KNCA
K
KCB
copper-constantan 40
copper
KPCB
constantan 40
KNCB
K
KX
Chromel10-NiSi3
Chromel10
KPX
NiSi3
KNX
N
NC
Iron-constantan 18
Iron
NPC
constantan 18
NNC
N
NX
NiCr14Si-NiSi4Mg
NiCr14Si
NPX
NiSi4Mg
NNX
E
EX
NiCr10-Constantan45
NiCr10
EPX
Constantan45
ENX
J
JX
Iron-constantan 45
Iron
JPX
constantan 45
JNX
T
TX
copper-constantan 45
copper
TPX
constantan 45
TNX
0.711mm KX thermocouple cable 22SWG quartz fiber insulation 1000C
Delivery and Package:
Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.
Delivery Detail: By sea/ air. About 7days, as the order quantity.
