Low Voltage Cable Sun Proof XLPE/PVC 2kv UL Type PV/Tc

YIFANG ELECTRIC GROUP INC.

Application：Construction, Underground
Voltage：0.6,1kv
Current：AC Cable
Insulation Material：XLPE
Sheath Material：PVC
Material Shape：Round Wire

Base Info

Model NO.：LV-BE35
Wire Core Material：Bare Copper Wire
Certification：ISO, CCC, CE
Model：LV-Be35
Brand：Yifang
Standard：UL
Transport Package：Wooden Drum or Wooden&Steel Drum
Specification：3* 10AWG
Trademark：Yifang
Origin：Zhengzhou City of Henan Province, China
HS Code：8544492100
Production Capacity：500 Kilometers,Month

Description

Basic Info.

Model NO. LV-BE35 Wire Core Material Bare Copper Wire Certification ISO, CCC, CE Model LV-Be35 Brand Yifang Standard UL Transport Package Wooden Drum or Wooden&Steel Drum Specification 3* 10AWG Trademark Yifang Origin Zhengzhou City of Henan Province, China HS Code 8544492100 Production Capacity 500 Kilometers/Month

Product Description

Sun Proof XLPE/PVC 2kV UL TYPE PV/TC

Applications

As three-conductor power cables rated 2000 volts, 90°C in dry or wet locations for Solar PV generation, this cable is connected to the tracker motors. Approved for installation in cable trays per Article 336 of the NEC. Type TC-ER cables are approved for use in Class 1, Division 2 hazardous locations. Cables may be installed in open air, in ducts or conduits, or in tray or trough. All cables when used in accordance with the NEC, meet the requirements of OSHA.

Specifications

Copper conductors conform to ASTM B-3 and B-8.
Insulated conductors RHH/RHW-2 Type per UL 44, USE-2 Type per UL 854, and PV Type per UL 4703, UL 1277 Type TC-ER
Cable is designed to pass the UL 1581, IEEE-383, IEEE-1202 and VW-1 flame tests.
Cable is suitable for sunlight resistant and direct burial applications, and is approved For CT Use.
Cable meets the requirements of ICEA S-95-658/NEMA WC70.

Construction

Stranded copper conductors, XLPE (Cross-Linked Polyethylene) insulation, Method 4 phase-identified; three insulated conductors cabled together with a stranded copper grounding conductor in one interstice, fillers as necessary, cable tape, black sunlight-resistant PVC (Polyvinyl Chloride) jacket overall, surface printed.
