Screened and Armoured Control Cable

YIFANG ELECTRIC GROUP INC.
  • Application：Construction, Underground, Industrial, Power Station, Telecommunication
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：PVC,XLPE,PE
  • Sheath Material：PVC or PE or Lshf
  • Material Shape：Round Wire

Base Info

  • Model NO.：Control cable
  • Wire Core Material：Copper
  • Certification：ISO, CCC, CE, RoHS, UL, VDE
  • Model：Control Cable
  • Brand：Yifang
  • Cores Number：up to 61core
  • Transport Package：Coil or Drum
  • Specification：0.75-16mm2
  • Trademark：Yifang cable
  • Origin：Zhengzhou, Henan, China
  • HS Code：8544494210
  • Production Capacity：500km Per Month

Description

Basic Info.

Model NO. Control cable Wire Core Material Copper Certification ISO, CCC, CE, RoHS, UL, VDE Model Control Cable Brand Yifang Cores Number up to 61core Transport Package Coil or Drum Specification 0.75-16mm2 Trademark Yifang cable Origin Zhengzhou, Henan, China HS Code 8544494210 Production Capacity 500km Per Month

Product Description

Screened and Armoured Control Cable

Manufacture according to ASTM, BS, DIN, NFC, AS/NZS, CSA, IS, etc.
1. Control cable is suitable for connecting wires between electric equipments in controlling, monitoring loop and protecting circuit at rated voltage up to and including 600/100V (A. C. ).

2. Cable structure:
2.1 Conductor: Cu, class1, class2, class5, class6
2.2 Insulation: PVC/PE/XLPE
2.3 Filler: PP Rope / Cable paper
2.4 Metallic screen (optional): Copper wire braiding / Copper tape/
2.5 Inner sheath (applicable if there is armour layer): PVC/PE
2.6 Armour: Galvanized steel wire / Steel tape
2.7 Outer sheath: PVC/PE/LSHF
2.8 Other characters: Oil resistant, Flame retardant, Anti-corrosion, etc.

3. Packing: Roll / Wooden drum/ Iron-wooden drum / Steel drum

For further information, pls contact us directly.
