• Model NO.：0.18*14mm
• Thickness：from 0.017 to 1.200 mm
• Transport Package：Platter
• Specification：0.18*1.4mm
• Trademark：General clad
• Origin：China
• Production Capacity：25000t,Year

Basic Info.

Model NO. 0.18*14mm Thickness from 0.017 to 1.200 mm Transport Package Platter Specification 0.18*1.4mm Trademark General clad Origin China Production Capacity 25000t/Year

Product Description



Base material copper: In accordance with EU-standard: DIN EN 13602 (Cu-ETP, Cu-ETP1, Cu-Of, Cu-Of1) In accordance with US-standard: ASTM B 224 - 80 Available in different strength classes according to DIN EN 13599

Optional coating on the base material: Tin (Sn), Silver (Ag), Nickel (Ni), and others on request

Dimensions: Thickness from 0.017 to 1.200 mm Width from 0.200 to 24.000 mm*     *> 6.000 mm width made of cut strip, re-rolled

Designs: Additional application-optimized strengths to your specifications available Edge shape: Milled round, cut

Features: Geometrical and mechanical values are reviewed and documented according to your requirements Tightest tolerances in terms of thickness and width Resistance measurement to defined specifications Manufactured to your customized specifications

Applications: Fuse wire or fusible conductor for safety fuses Welding wire Connecting wire Wire connector (PIN) Shielding wire for high-frequency cable (HF cable)
