Best Seller Acar Aluminum Conductor Alloy Reinforced
Henan Jiapu Cable Co., Ltd.- Type：Bare
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum
- Sheath Material：None
- Insulation Material：None
Base Info
- Model NO.：ACAR
- Material Shape：Round Wire
- Certification：ISO9001, CE, SABS
- Brand：Henan Jiapu
- Capacity：2000ton,Month
- Min.Order Qty：1km
- Delivery Length：Accord with The Request
- Certificate：SABS, ISO9001-2008, CQC Certificate, CE , SGS
- Port of Loading：Tianjin, Qingdao, Ningbo, Shanghai, Xiamen
- Payment Term：L,C, D,P, D,a ,T,T, M,T, D,D, O,a, C.W.O, C.O.D, C
- Transport Package：Drum
- Specification：IEC ASTM BS DIN, Any standard
- Trademark：Jiapu
- Origin：Zhengzhou
- HS Code：7614100000
- Production Capacity：2000ton,Month
Description
Code NumberNumber of Wires A1/A2 Conductor A1/A3 Conductor Max.D.C.
Resistance Al Alloy Dia. Of Wires Dia.of Conductor Approx. Weight Rated Strength Dia. Of Wires Dia.of Conductor Approx. Weight Rated Strength mm2 - - mm mm kg/km kN mm mm kg/km kN Ω/km 16 4 3 1.76 5.28 46.6 3.85 1.76 5.29 46.8 4.07 1.7896 25 4 3 2.2 6.6 72.8 5.93 2.21 6.62 73.1 6.29 1.1453 40 4 3 2.78 8.35 116.5 9.25 2.79 8.37 117 9.82 0.7158 63 4 3 3.49 10.5 183.5 14.38 3.5 10.5 184.3 14.8 0.4545 100 4 3 4.4 13.2 291.2 22.52 4.41 13.2 292.5 23.49 0.2863 125 12 7 2.97 14.9 362.7 27.79 2.98 14.9 364.1 29.29 0.2302 160 12 7 3.36 16.8 464.2 35.04 3.37 16.9 466 36.95 0.1798 200 12 7 3.76 18.8 580.3 43.13 3.77 18.8 582.5 44.78 0.1439 250 12 7 4.21 21 725.3 53.92 4.21 21.1 728.1 55.98 0.1151 250 18 19 3.04 21.3 742.2 60.39 3.05 21.4 746 64.67 0.1154 315 30 7 3.34 23.4 892.6 60.52 3.34 23.4 894.4 62.4 0.0916 315 18 19 3.42 23.9 935.1 76.09 3.43 24 940 81.48 0.0916 400 30 7 3.76 26.3 1133.5 75.19 3.77 26.4 1135.8 76.82 0.0721 400 18 19 3.85 27 1187.5 95.58 3.86 27 1193.7 100.3 0.0721 450 30 7 3.99 27.9 1275.2 84.59 3.99 28 1277.8 86.42 0.0641 450 18 19 4.08 28.6 1335.9 107.52 4.1 28.7 1342.9 112.84 0.0641 500 30 7 4.21 29.4 1416.9 93.98 4.21 29.5 1419.8 96.03 0.0577 500 18 19 4.31 30.1 1484.3 119.47 4.32 30.2 1492.1 125.38 0.0577 560 30 7 4.45 31.2 1586.9 105.26 4.46 31.2 1590.1 107.55 0.0515 560 54 7 3.45 31 1571.9 101.54 3.45 31.1 1573.9 103.53 0.0516 630 42 19 3.71 33.4 1820 130.25 3.72 33.4 1826 134.59 0.0458 630 24 37 3.79 34.1 1897.5 160.19 3.8 34.2 1909 169.14 0.0458 710 42 19 3.94 35.5 2051.2 146.78 3.95 35.5 2057.8 151.68 0.0407 710 24 37 4.02 36.2 2138.4 180.53 4.03 36.3 2151.4 190.61 0.0407 800 42 19 4.18 37.6 2311.2 165.39 4.19 37.7 2318.7 170.9 0.0361 800 24 37 4.27 38.4 2409.5 203.41 4.28 38.5 2424.2 214.78 0.0361 900 42 19 4.43 39.9 2600.1 186.06 4.44 40 2608.5 192.27 0.0321 900 54 37 3.66 40.2 2638.4 199.54 3.66 40.3 2649.5 207.79 0.0321 1000 72 19 3.8 41.8 2849.1 190.94 3.8 41.8 2855.4 195.47 0.0289 1000 54 37 3.85 42.4 2931.6 221.71 3.86 42.5 2943.9 230.88 0.0289 1120 72 19 4.02 44.2 3191 213.85 4.02 44.3 3198.1 218.92 0.0258 1120 54 37 4.08 44.9 3283.4 248.32 4.09 45 3297.2 258.58 0.0258 1250 72 19 4.25 46.7 3561.4 238.68 4.25 46.8 3569.3 244.33 0.0231 1250 54 37 4.31 47.4 3664.5 277.14 4.32 47.5 3679.9 288.6 0.0231 1400 72 19 4.5 49.4 3988.8 267.32 4.5 49.5 3997.6 273.65 0.0207
Resistance
