Mcptj-0.66/1.14 Individual Metallic Screen Metal-Screened Monitoring Rubber-Sheathed Soft Cable

Tianjin Feiya Electric Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Chemisty Power Gmernting and Metallurgy
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：Rubber

Base Info

  • Model NO.：MCPTJ-0.66,1.14
  • Material Shape：Round Wire
  • Range of Application：Chemisty Power Gmernting and Metallurgy
  • Certification：ISO9001, CE, UL, CCC, RoHS, VDE
  • Brand：Feiya
  • OEM：Yes
  • Transport Package：Wooden Box Packing or Pallet Shipping Containers
  • Specification：copper
  • Trademark：Feiya
  • Origin：China
  • HS Code：854449210
  • Production Capacity：50K Meter Per Year

Description

Introduction1Can be customized according to requirements.2Independent brand recruitment agency.3High quality, ISO 9001, CCC, CE, RoHS certified.4ODM&OEM is available.Mcptj-0.66/1.14 Individual Metallic Screen Metal-Screened Monitoring Rubber-Sheathed Soft CableMcptj-0.66/1.14 Individual Metallic Screen Metal-Screened Monitoring Rubber-Sheathed Soft CableMcptj-0.66/1.14 Individual Metallic Screen Metal-Screened Monitoring Rubber-Sheathed Soft Cable Applications:
     YFFB Series Cable is special designed for frequent motion and flexing.  This cable
can be used for festoon systems, power tracks, cable tenders, cranes and hoists.

Feature:
Sheath: Special polychloreprene (Butadiene-Acrylonitrile Rubber) which is flame
resistance and self-extinguishing.
Conductor: Superfine Soft Bare Copper which purity can reach 99.999%.
Insulation: Special polychloreprene (Butadiene-Acrylonitrile Rubber)

Technical data:
Rated voltage: ≤1.5mm2 300/500V     >1.5mm2:  450V/750V
Test voltage:   ≤1.5mm2 2500V          >1.5mm2:  3000V
Temperature range: -20°C to +80°C

ModelQty of CoresSection of Cores
mm2		Width of Cable
mm		Thickness of Cable
mm		Weight
kg/km
YFFB41.516.35.8198.4
YFFB42.518.76.6268.4
YFFB4421.97.3367.7
YFFB4626.98.0507.6
YFFB41034.59.7784.1
YFFB41638.510.71074
YFFB4254712.81575
YFFB43556.615.22245

YFFB61.523.35.8282.8
YFFB62.526.96.6386.5
YFFB6431.77.3534.2
YFFB6638.78.0737
YFFB61050.19.71148
YFFB61656.110.71580
YFFB62568.612.82322
YFFB63582.615.23311

YFFB81.529.35.8358.8
YFFB82.5366.6513.3
YFFB8440.57.3690
YFFB8648.98.0947.7
YFFB81063.99.71486
YFFB81671.910.72057
YFFB82588.212.83031

YFFB101.535.35.8434.7
YFFB102.541.36.6603.3
YFFB10449.37.3845.9
YFFB10659.18.01158
YFFB101077.79.71824
YFFB101687.710.72535

YFFB121.541.35.851.7
YFFB122.548.56.6711.8

YFFB161.047.14.8475.5
YFFB161.554.35.8671
YFFB162.563.96.6838.3

YFFB201.058.34.8587.9
YFFB201.567.35.8831.4
YFFB202.579.36.61165
