UL1185 Bare Copper Conductor PVC Insulation Aluminum Shielded Single Core Stranded Copper Electrical Wire

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：for General Purpose Internal Wiring of Appliance
  • Conductor Material：Copper
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：UL1185
  • Range of Application：Flame Retardant
  • Certification：ISO9001, UL, RoHS, Reach
  • Brand：B&T
  • Rated Temperature：80 ºC
  • Rated Voltage：30V
  • According to：UL Subject758, UL1581, C22.2
  • Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
  • Performance：for General Purpose Internal Wiring of Appliance
  • Conductor：Stranded, Tinned or Bare Copper Conductor
  • Capacity：300,000km Annual
  • Color：Could Be Customized Color
  • Delivery Time：7-15days
  • Package：Coil or Spool Packing
  • Transport Package：610feet in Roll
  • Specification：ul1185
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

NO.of Cond/mmInsulated Thick.Braid ShieldJacket Thick.Outside Thick.mmNo./dmmmm307/0.10.4132/0.100.40 2.10 287/0.1270.4134/0.100.40 2.20 267/0.160.4137/0.100.40 2.30 2411/0.160.4140/0.100.40 2.40 2217/0.160.4145/0.100.40 2.60 2021/0.1780.4150/0.100.40 2.80 1834/0.1780.4158/0.100.40 3.10 1626/0.2540.4166/0.100.40 3.40 281/0.3200.4133/0.100.40 2.15 261/0.4040.4136/0.100.40 2.25 241/0.5110.4138/0.100.40 2.35 221/0.6430.4142/0.100.40 2.50 201/0.8130.4146/0.100.40 2.65 181/1.0240.4151/0.100.40 2.85

UL1185 Bare Copper Conductor PVC Insulation Aluminum Shielded Single Core Stranded Copper Electrical WireUL1185 Bare Copper Conductor PVC Insulation Aluminum Shielded Single Core Stranded Copper Electrical WireUL1185 Bare Copper Conductor PVC Insulation Aluminum Shielded Single Core Stranded Copper Electrical WireUL1185 Bare Copper Conductor PVC Insulation Aluminum Shielded Single Core Stranded Copper Electrical WireUL1185 Bare Copper Conductor PVC Insulation Aluminum Shielded Single Core Stranded Copper Electrical Wire
