• OEM/ODM：Yes
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：copper
• Trademark：feiya
• Origin：Tianjin, China

Basic Info.

OEM/ODM Yes Transport Package Wooden Box Packing or Pallet Shipping Containers Specification copper Trademark feiya Origin Tianjin, China

Product Description

Application

    This product is suitable for electric vehicle conduction charging continuous device, AC or DC power supply network (power) is adjusted to standard voltage / current to provide electric energy for electric vehicle power battery, it can also supply power to the on-board equipment.

   The rated voltage of this product is AC 450/750V and below, DC 0.6/1kV and below(includes signal wire core and control wire core).


Type and Designation

Model	Designation
SS	Thermoplastic Elastomer Insulation & sheath electric vehicle charging cable
SSPS	Thermoplastic elastomer insulated copper wire braid shielding thermoplastic elastomer sheath and sheath electric vehicle charging cable
Model	Designation
SF	Thermoplastic Elastomer Insulation thermosetting elastomer sheath electric vehicle charging cable
SSPF	Thermoplastic elastomer insulated copper wire braid shielding thermoplastic elastomer sheath, thermosetting elastic sheath, electric vehicle charging cable
S90S90	Thermoplastic Elastomer Insulation & sheath electric vehicle charging cable
S90S90PS90	Thermoplastic elastomer insulated copper wire braid shielding thermoplastic elastomer sheath and sheath electric vehicle charging cable
S90F	Thermoplastic Elastomer Insulation thermosetting elastomer sheath electric vehicle charging cable
S90S90PF	Thermoplastic elastomer insulated copper wire braid shielding thermoplastic elastomer sheath, thermosetting elastic sheath, electric vehicle charging cable
S90U	Thermoplastic elastomer insulated polyurethane elastomer sheath cable for electric vehicle charging
S90S90PU	Thermoplastic elastomer insulated copper wire braid shielding thermoplastic elastomer sheath, Polyurethane elastomer sheath, electric vehicle charging cable
S90S90UPU	Thermoplastic elastomer insulated copper wire braid shielding Polyurethane elastomer sheath, Polyurethane elastomer sheath, electric vehicle charging cable
EU	Ethylene propylene rubber or similar synthetic rubber insulation Polyurethane elastomer sheath electric vehicle charging cable
EUPU	Ethylene propylene rubber or similar synthetic rubber insulated copper wire woven shield Polyurethane elastomer sheath and sheath cable for electric vehicle charging
EF	Ethylene propylene rubber or similar synthetic rubber insulation thermosetting elastomer sheath electric vehicle charging cable
EFPF	Ethylene propylene rubber or similar synthetic rubber insulated copper wire braid shielding thermosetting inner sheath and sheath electric vehicle charging cable

Technical performance

1.450/750V    Rated voltage AC 450/750V
     0.6/1kV      Rated voltage DC 0.6/1kV

2.The range of environmental temperature is -40ºC to +50ºC, he cable should be chosen according to the environmental temperature.

3.The cable shall comply with the single flame retardant test requirements specified in GB/T 18380.12-2008

4.This product should be based on GB/T 20234-2015 "electric vehicle conductive charging connection device" in the second part: AC charging interface; the third part: DC charging interface required production.

FAQ

Q1:Are you a trading company or manufacturer?

A1: Tianjin Feiya wire & Cable CO., LTD. is a professional manufacturer.

Q2: What kinds of products does Tianjin Feiya wire & Cable CO., LTD. manufacture?

A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable,PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable,coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.

Q3:Which standards do you comply with when you produce the electrical wires and cables ?

A3: We have passed ISO9001:2000 and ISO140001:2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).

Q4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.

Q5:How much the Courier freight will be for the samples?

A5:Courier freight depends on the quantity,weight and carton size and your area.
