SAE J1128 PVC Insulation Gpt Wire 12AWG 16AWG 18AWG 20AWG Automotive Cable Wire Ignition Wire

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Car Cable
  • Conductor Type：Stranded
  • Application：Low Voltage Wiring of Vehicle
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：GPT
  • Material Shape：Round Wire
  • Certification：CE, UL, CCC, RoHS, VDE
  • Brand：Bort
  • Color：White, Black, Red, Yellow, Blue, Green, etc
  • Weight：About 1kg,1000FT
  • Rated Voltage：60V
  • Sample：Normal Sample Free
  • Producing Experience：10 Years
  • Packing：100m,Roll, 305m,Roll,Wrap Plastic Film Packing
  • Company Type：Manufacture
  • Character：Resistant to Heat, Oil, Abrasion and Cold
  • Service：OEM,ODM
  • Factory Management：ISO9001:2008
  • Transport Package：Coil
  • Trademark：BORT
  • Origin：China
  • HS Code：8544492900
  • Production Capacity：50000km,Per Year

Description

AWGNO.of CondDia.Insulation Thick.Overall Dia.STRENGTHNo./mmmmmmmm(VAC1min)207/0.3210.582.210002019/0.1910.582.210001819/0.231.20.582.410001619/0.291.50.582.610001419/0.361.80.58310001219/0.452.30.663.610001019/0.5830.794.51000850/0.453.70.945.61000
