Pure Copper Rg59+2c Coaxial Cable for CCTV Camera
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：coaxial cable
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS
- Brand：OEM
- Powe Wire：2X0.75sq mm
- Transport Package：200m,300m,305m
- Specification：0.8mm Conductor
- Origin：China
- HS Code：8544200000
- Production Capacity：1500km,Month
Description
Basic Info.
Model NO. coaxial cable Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS Brand OEM Powe Wire 2X0.75sq mm Transport Package 200m/300m/305m Specification 0.8mm Conductor Origin China HS Code 8544200000 Production Capacity 1500km/MonthProduct Description
Outdoor UTP Cat5e CCTV copper Siamese Cable with CCA power wireRG59 Siamese CCTV cable allows installers to run both the video and power to security cameras (analog CCTV, 720p and 1080p HD cameras) using a single cable run.
RG-59 coaxial cable comes in 500 and 1000 foot spools and is available in black or white colors.
The RG59 cable that CCTV Camera Pros supplies has a solid copper core and 95% copper braided shielding.
This is the best type of coax cable to use for CCTV and HD CCTV installations.
FeaturesRG59 + Power Siamese CableWooden SpoolGreat for CCTV and security systems18 AWG Gauge (power) and 23 AWG CCA (RG59)UV resistant PE jacketETL CertifiedRG5923AWG Solid Copper Conductor3.67mm Solid PE Dielectric112 CCA Braiding 90% coveragePVC Jacket6 mm DiameterNominal Impedance - 75 ONominal Propegation Velosicty - 85%Nominal Capacitance 50 Pf/mPower18 AWG 2 Conductor16/30 stranded CCA (copper clad aluminum)Black and Red PE jacketOuter JacketUV resistant PE7.5 x 9.3mm OD.
| TECHNOLOGY DATA | |
|---|---|
| Characteristic Impedance | 75±3Ohm |
| Capacitance | 50±1pF/m |
| Velocity | >85% |
| Shielding Effectiveness | >100db |
| Insulation resistance | 1000MOhm(20ºC) |
| Frequence (at 20ºC) | Max.Attenuation |
| 5MHz | 2.82dB/100m |
| 55MHz | 6.73dB/100m |
| 211MHz | 12.47dB/100m |
| 350MHz | 15.75dB/100m |
| 450MHz | 17.72dB/100m |
| 500MHz | 18.70dB/100m |
| 550MHz | 19.52dB/100m |
| 750MHz | 22.87dB/100m |
| 1000MHz | 26.64dB/100m |
| 1450MHz | 32.41dB/100m |
| 1750MHz | 36.04dB/100m |
