High Density 12 Cores MPO/MTP 62.5/125 Multimode Trunk Cable Assemblies

Shenzhen Lightwit Photonics Co., Ltd.
  • Application：Communication, Art, Sensor, Medicine, Probe
  • Type：Single-mode Fiber
  • Connection Structure：LC
  • Material Shape：Flat Wire
  • Allowed Lateral Pressure：>1000(N,100mm)
  • Allowed Tensile Strength：1000N<10000N

Base Info

  • Model NO.：LW-MPO001
  • Core：Multicore
  • Certification：RoHS, UL, CE, ISO9001, VDE, CCC
  • Brand：OEM
  • Sheath Material：PVC
  • Keywords：MTP,MPO to LC,LC
  • Connector Type：MPO,MTP,LC,Dlc
  • Product Name：Duplex LC MPO-LC Harness Cables
  • Acket Materials：LSZH,Ofnr,PVC
  • 3D Testing：100%
  • Jacket Colors：Yellow, Aqua , Erika Violet,Purple
  • Fiber Core：8 Core ,12 Core , 24 Core
  • Transport Package：Paper Box
  • Specification：1M 2M 3M
  • Trademark：LIGHTWIT
  • Origin：Shenzhen, China
  • HS Code：8544492900
  • Production Capacity：50000

Description

Fiber Type OS2,OM1,OM2,OM3,OM4,OM5Fiber Count 8/12/24 coresCable Diamter 3.0mm 5.5mm or customized Jacket ColorYeloow, Orange, Aqua, PurpleJacket Material OFNR, OFNP, PVC, LSZHTensile Strength 500NOperating Temperature -20 to 70 ºCStorage Temperature -40 to 75ºC

 Performance LevelStandardEliteConnectorModeEndfaceIL(max) (dB)RL(min) (dB)IL(max) (dB)RL(min) (dB)MPO/MTPSM12F/APC≤0.70≥60≤0.35≥6024F/APC≤0.75≥60≤0.35≥6048F/APC≤0.75≥60  MM12F/PC≤0.50≥20≤0.35≥2024F/PC≤0.50≥20≤0.35≥2048F/PC≤0.50≥20

Note:
1.Test wavelength:SM@1310/1550nm,MM@850/1300nm;
2.Standard conformance: GR-326,GR-1435.


Our MPO/MTP Series

MPO/MTP Trunk Cable
MPO/MTP Harnesses Cables
MPO/MTP Fan out 0.9mm Patch Cords
IP-Series MPO/MTP Assembly
High Density Patch Cords
MPO/MTP Loopback
MT Patch Cords
MPO/MTP Cassettes
MPO/MTP Fiber Optic Patch Panel
