Rg8 95% Shield Coax Cable with Stranded Copper Conductor Low Loss
Jiangsu Elesun Cable Co., Ltd.- Application：Coaxial Cable
- Conductor Material：Copper
- Cover Material：PVC
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：RG8U
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, UL
- Brand：Elesun
- Impedance：50 Ohm
- Velocity Ratio：87%
- Bent Radius：50mm
- Max Frequency：3000
- Color：White Black
- Transport Package：Pallet
- Specification：144*0.15TC
- Trademark：ELESUN
- Origin：China
- HS Code：8544200000
- Production Capacity：300km,Month
Description
Low loss antenna extension RF cable assembly RG8,ALSR400 N male/SMA male
Material of Inner Conductor
Bare Copper
Structure of Inner Conductor
7/0.724mm
Material of Insulation
Foam PE
Diameter of Insulation
7.24mm
Material of Braiding(Shielding)
CCA, Bare Copper, Tinned Copper
Structure of Braiding(Shielding)
168*0.15mm
Material of Jacket
PVC
Diameter of Jacket
10.30mm
Working temp
-40ºC/80ºC
Impedance
50Ω±2
Voltage
4000V
Weight
160KG/KM
FAQQ: Can I have a sample testing before mass order?
Yes, We provide samples free and sample freight charge will be paid by customer. Sample delivery time is quick.
Q: What about the lead time of production
Usually it is 10-15days, for cables above 300KM delivery time is about 20-25 days
Q: Do you have MOQ limit for order
Normally 1KM each item, for special order less than 1KM we can check together.
Q: How about shipment way?
For samples which we choose UPS/DHL/TNT/FEDEX and for sea shipment we choose SHA or NINGBO port
Q: Is it OK to print our logo on the cable?
Yes Of course,just forward us your details before placing order.
Q: How do you solve the problem of after sale service
Quality is the priority rule in our company, we will make sure the quality before delivery and any
feedback from customer we will handle and replace asap.
