Outdoor Aerial Non Metallic Fiber Optical Cable ADSS
Zhejiang Fuchunjiang Photoelectric Science Technology Co., Ltd.- Application：Communication
- Type：Single-mode Fiber
- Connection Structure：No
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：1000N<10000N
Base Info
- Model NO.：ADSS
- Core：Multicore
- Certification：RoHS, UL, CE, ISO9001, CCC
- Brand：Fcj Opto Tec.
- Sheath Material：TPU, LSZH, PE, PVC
- Cable Type：Outdoor Aerial Non Metalic Optical Fiber Cable
- Optical Fiber：G652D, G657A or Customized
- Span：80m, 120m, 150m, 200m, 250m, 300m
- Mode：Single Mode or Multi Mode
- Loose Tube Material：PBT
- Strength Member：FRP
- Outer Sheath：PE, HDPE, TPU
- Transport Package：Wooden Drum
- Specification：1km, 2km, 3km
- Trademark：FCJ OPTO or customized
- Origin：China
- HS Code：854470000
- Production Capacity：8000km,Week
Description
G.652
G.655
50/125μm
62.5/125μm
Attenuation
(+20ºC)
@850nm
≤3.0 dB/km
≤3.0 dB/km
@1300nm
≤1.0 dB/km
≤1.0 dB/km
@1310nm
≤0.00 dB/km
≤0.00dB/km
@1550nm
≤0.00 dB/km
≤0.00dB/km
Bandwidth(Class A)
@850nm
≥500 MHz·km
≥200 MHz·km
@1300nm
≥500 MHz·km
≥500 MHz·km
Numerical aperture
0.200±0.015NA
0.275±0.015NA
Cable Cutoff Wavelength
≤1260nm
≤1480nm
Optical fiber cable parameters:
Cable Diameter
mm
Cable Weight
kg/km
Recommend maximum working tension
kN
Maximum allowable working tension
kN
breaking tenacity
kN
Section area of tensile components
mm2
modulus of elasticity
kN/ mm2
thermal expansion coefficient ×10-6 /k
PE sheath
AT sheath
9.8
121
130
1.5
4
10
4.6
7.6
1.8
10.2
129
138
2.1
5
14
6.9
8.1
1.4
13.1
132
143
2.8
7
19
9.97
9.13
1.2
15.6
189
207
3.8
9
26
14.2
11.2
1.0
- Color code:
