• Wire Core Material：Red Copper Wire
• Certification：ISO, CCC
• Model：YJV
• Brand：OEM
• Transport Package：in Drum
• Specification：95
• Trademark：OEM
• Origin：Henan
• HS Code：8544492100
• Production Capacity：10000 M Per Day

TypeDesignationApplicationVVCopper conductor ,PVC insulated ,PVC sheathed power cableFor laying indoors, in tunnel or cable trench,unable to bear extermal mechanical forces. Single core cable is not permissible to lay in magnetic ductVLVAluminium conductor ,PVC insulated ,PVC sheathed power cableVYCopper conductor, PVC insulated, PE sheathed power cableVLYAluminium conductor ,PVC insulated ,PE sheathed power cableVV22Copper conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cableFor laying indoors, in cable trench or direct in ground ,able to bear external mechanical forces, but unable to bear pulling forceVLV22Aluminium conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cableVV23Copper conductor ,PVC insualted ,steel tape armoured ,PE sheathed power cableVLV23Alunminium conductor ,PVC insulated ,steel tape armoured ,PE sheathed power cableVV32Copper conductor, PVC insulated, steel wire armoured,PVC insulated power cable
 For laying indoors, in cable or direct in ground ,able to bear external mechanical forces, but unable to bear large pulling forcesVLV32Aluminium conductor, PVC insulated ,steel tape armoured ,PVC sheathed power cableVV33Copper conductor, PVC insulated steel wire armoured , PE sheathed power cableVLV33Aluminium conductor , PVC insulated , streel wire armoured ,PE sheathed power cableNote: The armoured single core cables is only used for D.C.system. As for A.C.system,non-magnetic armored material should be applied
4. Nominal Cross-sectional Areas:
1.5 mm2 , 2.5 mm2  ,4 mm2 , 6 mm2 , 10 mm2  , 16 mm2 ,25 mm2  , 35 mm2 , 50 mm2  ,70 mm2  , 95 mm2  ,120 mm2  ,150 mm2 ,185 mm2  ,240 mm2 ,300 mm2  400 mm2 500 mm2 630 mm2 800 mm2

5. Production Range:
single core cable from 1.5 mm2  to 800 mm2,muli-core cable from 1.5 mm2   to 400 mm2

6. Operating Characteristics:
Rated power-frequency voltage u0/u:0.6/1 KV
Max permissible continuous operating temperature of conductor 70
Max short-circuit temperature of the conductor shall not exceed (Max 5 seconds duration): cross-section of conductor  300 mm2

The ambient temperature under installations should not be below 0

The bending radius of single core cable should not be less than 20 times of the cable diameter ,the bending radius of multi-core cable should not be less than 15 times of the cable diameter.
