• Model NO.：XHHW-2
• Material Shape：Round
• Range of Application：Flame Retardant
• Certification：ISO9001, CE, CCC
• Brand：Yifang
• Standard：UL 44
• Transport Package：Treated Wooden Drums
• Specification：16AWG TO 500MCM
• Trademark：YIFANG
• Origin：China
• HS Code：8544492100
• Production Capacity：10000m Per Week

Basic Info.

Model NO. XHHW-2 Material Shape Round Range of Application Flame Retardant Certification ISO9001, CE, CCC Brand Yifang Standard UL 44 Transport Package Treated Wooden Drums Specification 16AWG TO 500MCM Trademark YIFANG Origin China HS Code 8544492100 Production Capacity 10000m Per Week

Product Description

XHHW-2 600V Type RW-90 Building Wire

Application

Type XHHW-2, type RW-90 building wire is intended for general purpose applications utilized in conduit or other recognized raceways for services, feeders, and branch-circuit wiring, as specified in the National Electrical Code (NEC). Type XHHW-2 is permitted to be used in wet or dry locations at temperatures not to exceed 90oC. Industrial environments where superior insulation toughness and chemical resistance are required. Type XHHW-2 is permitted for 600 volts applications. 1/0 AWG and larger may be used in cable tray in accordance with the National Electrical Code. 1/0 AWG and larger comply with IEEE 1202/UL FT4 flame test and ICEA T-29-520 (210,000 Btu/hr) flame test.

Compliances

• UL 44 - Thermoset-Insulated Wires and Cables
• UL 1685 - CT Flame Exposure Test
• UL 1581- Flame Exposure Test (VW-1)
• IEEE 1202/FT4 (2/0 AWG and larger)
• Flame Test (70,000 Btu/hr Vertical Tray Test)
• ICEA T-29-520 (210,000 Btu/hr) flame test
• ICEA S-95-658 (NEMA WC70)

Construction

Conductor	Single copper conductor, stranded tinned annealed copper per ASTM B3 Class B stranding per ASTM B8
Insulation	Flame-retardant and moisture resistant Cross-Linked Polyethylene (FRXLPE)
Color	upon request, black is preferable



AWG/ kcmil	Strand	Nominal Conductor Diameter	Nominal Insulation Thickness	Nominal Overall Diameter	Copper Weight	Cable Weight
		Inch/mm	Inch/mm	Inch/mm	Lbs/kft	kg/km
14	7	0.07	1.80	0.030	0.76	0.13
12	7	0.09	2.26	0.030	0.76	0.15
10	7	0.11	2.87	0.030	0.76	0.18
8	7	0.14	3.56	0.045	1.14	0.24
6	7	0.18	4.57	0.045	1.14	0.28
4	7	0.23	5.84	0.045	1.14	0.33
2	7	0.29	7.37	0.045	1.14	0.39
1	19	0.32	8.13	0.055	1.40	0.44
1/0	19	0.36	9.14	0.055	1.40	0.48
2/0	19	0.41	10.41	0.055	1.40	0.53
3/0	19	0.46	11.68	0.055	1.40	0.58
4/0	19	0.51	12.95	0.055	1.40	0.63
250	37	0.56	14.22	0.065	1.65	0.70
350	37	0.66	16.76	0.065	1.65	0.80
400	37	0.73	18.54	0.065	1.65	0.87
500	37	0.79	20.07	0.065	1.65	0.93
600	61	0.87	22.10	0.080	2.03	1.04
750	61	0.98	24.89	0.080	2.03	1.15
