• Model NO.：H07V-U , H07V-F, H05V-U
• Range of Application：Whthin The Equipment and The Light Unit
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE, CSA
• Brand：Feiya
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：US $0.1-0.99, Meter
• Trademark：FengDa
• Origin：Tianjin, China
• HS Code：8544492100
• Production Capacity：5, 000, 000km,Year

Basic Info.

Model NO. H07V-U / H07V-F/ H05V-U Range of Application Whthin The Equipment and The Light Unit Certification ISO9001, CE, UL, CCC, RoHS, VDE, CSA Brand Feiya Transport Package Wooden Box Packing or Pallet Shipping Containers Specification US $0.1-0.99/ Meter Trademark FengDa Origin Tianjin, China HS Code 8544492100 Production Capacity 5, 000, 000km/Year

Product Description

Product Description:

Type: H07V-U/H07V-F(60227 IEC 01)

Application:Suitable fordry locations, in switchboards and switchboard'sindoor fixing installation,installed in surface mounted,embedded conduits, orsuitably objects.

Conductor: Solid or stranded bare copper(acc.DIN EN 60228 Class 1 or 2)
Insulation: PVC
Color: Red, Black, Blue,Brown, Grey, White, Green/Yellow, Yellow, Green
Rated voltage:450/750V
Standard:IEC60227-3   DIN VDE 0281-3
Maximum conductor temperature:70°C
Test voltage:2500V


Type: H05V-U (60227 IEC 05)

Application:Suitable for protectedfixed installations within the equipment andwithin the lighting unit or on the lighting unit, as well as for installations in pipesabove and below the gypsum, for signal circuits and control circuits only.

Conductor:Solid bare copper(acc.DIN EN 60228 Class 1 or 2)
Insulation:PVC
Color:Red,Black, Blue,Brown, Grey, White, Green/Yellow, Yellow, Green
Rate voltage:300/500V
Standard:IEC 60227-3   DIN VDE 0281-3
Test voltage:2000V
Temperature range:+5°C till +70°C
Bending radius:Min 4 times diameter
