Triplex (2+1) Service Drop Aluminum Conductor Cable
YIFANG ELECTRIC GROUP INC.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum
- Insulation Material：XLPE or PVC or PE
- Certification：ISO9001
Base Info
- Model NO.：Triplex
- Product Name：Triplex Service Drop Aluminum Cable Conductor
- Transport Package：Drum Or As Your Request
- Specification：IEC, JIS, DIN, ANSI, CSA. etc
- Trademark：YIFANG
- Origin：China
- HS Code：8544492100
- Production Capacity：5, 000 Kilometers Per Month
Description
| Item # | Phase conductor size AWG | Phase conductor stranding | Phase conductor Insulation Thickness | Bare Neutral Messenger Size AWG | Bare Neutral Messenger Stranding | Bare Neutral Messenger breaking strength | Weight Per 1000ft-XLP | Weight Per 1000ft-Poly | Ampacity -XLP | Ampacity -Poly |
| Haiotis | 6 | Solid | 45 mls | 6 | 7 | 563 Lbs | 102.5 Lbs | 98.8 Lbs | 85 Amps | 70 Amps |
| Patella | 6 | 7/w | 45 mls | 6 | 7 | 563 Lbs | 109.1 Lbs | 101.6 Lbs | 85 Amps | 70 Amps |
| Fusus | 4 | Solid | 45 mls | 4 | 7 | 881 Lbs | 151.9 Lbs | 147.6 Lbs | 115 Amps | 90 Amps |
| Oyster | 4 | 7/w | 45 mls | 4 | 7 | 881 Lbs | 161.8 Lbs | 151.7 Lbs | 115 Amps | 90 Amps |
| Clam | 2 | 7/w | 45 mls | 2 | 7 | 1350 Lbs | 243.2 Lbs | 229.2 Lbs | 150 Amps | 120 Amps |
| Murex | 1/0 | 7/w | 60 mls | 1/0 | 7 | 1990 Lbs | 395.1 Lbs | 369.4 Lbs | 205 Amps | 160 Amps |
| Purpura | 1/0 | 19/w | 60 mls | 1/0 | 7 | 1990 Lbs | 386.1 Lbs | 369.4 Lbs | 205 Amps | 160 Amps |
| Nassa | 2/0 | 7/w | 60 mls | 2/0 | 7 | 2510 Lbs | 485.8 Lbs | 455.3 Lbs | 235 Amps | 185 Amps |
| Melita | 3/0 | 19/w | 60 mls | 3/0 | 19 | 3310 Lbs | 585.2 Lbs | 562.9 Lbs | 275 Amps | 215 Amps |
| Portunus | 4/0 | 19/w | 60 mls | 4/0 | 19 | 4020 Lbs | 723.9 Lbs | 697.3 Lbs | 315 Amps | 245 Amps |
| Nannynose | 336.4 | 19/w | 80 mls | 336.4 | 19 | 6146 Lbs | 1160.4 Lbs | 1118.0 Lbs | 420 Amps | 325 Amps |
| Paludina | 6 | Solid | 45 mls | 6 | 6/1 | 1190 Lbs | 114 Lbs | 113 Lbs | 85 Amps | 70 Amps |
| Voluta | 6 | Solid | 45 mls | 6 | 6/1 | 1190 Lbs | 114 Lbs | 113 Lbs | 85 Amps | 70 Amps |
| Whelk | 4 | Solid | 45 mls | 4 | 6/1 | 1860 Lbs | 169 Lbs | 165 Lbs | 115 Amps | 90 Amps |
| Periwinkle | 4 | 7 | 45 mls | 4 | 6/1 | 1860 Lbs | 176 Lbs | 172 Lbs | 115 Amps | 90 Amps |
| Conch | 2 | 7 | 45 mls | 2 | 6/1 | 2850 Lbs | 267 Lbs | 261 Lbs | 150 Amps | 120 Amps |
| Neritina | 1/0 | 7 | 60 mls | 1/0 | 6/1 | 4380 Lbs | 530 Lbs | 419 Lbs | 205 Amps | 160 Amps |
| Cenia | 1/0 | 19 | 60 mls | 1/0 | 6/1 | 4380 Lbs | 426 Lbs | 416 Lbs | 205 Amps | 160 Amps |
| Runcina | 2/0 | 7 | 60 mls | 2/0 | 6/1 | 5310 Lbs | 530 Lbs | 519 Lbs | 235 Amps | 185 Amps |
| Triton | 2/0 | 19 | 60 mls | 2/0 | 6/1 | 5310 Lbs | 526 Lbs | 514 Lbs | 235 Amps | 185 Amps |
| Cherrystone | 3/0 | 7 | 60 mls | 3/0 | 6/1 | 6620 Lbs | 656 Lbs | 643 Lbs | 250 Amps | 200 Amps |
| Mursia | 3/0 | 19 | 60 mls | 3/0 | 6/1 | 6620 Lbs | 650 Lbs | 638 Lbs | 250 Amps | 200 Amps |
| Razor | 4/0 | 7 | 60 mls | 4/0 | 6/1 | 8350 Lbs | 814 Lbs | 799 Lbs | 315 Amps | 245 Amps |
| Zuzara | 4/0 | 19 | 60 mls | 4/0 | 6/1 | 8350 Lbs | 805 Lbs | 792 Lbs | 315 Amps | 245 Amps |
| Limpet | 336.4 | 19 | 80 mls | 336.4 | 18/1 | 8680 Lbs | 1209 Lbs | 1167 Lbs | 420 Amps | 325 Amps |
| Scallop | 4 | Solid | 45 mls | 6 | 6/1 | 1190 Lbs | 148 Lbs | 144 Lbs | 115 Amps | 90 Amps |
| Strombus | 4 | 7/w | 45 mls | 6 | 6/1 | 1190 Lbs | 158 Lbs | 148 Lbs | 115 Amps | 90 Amps |
| Cockle | 2 | 7/w | 45 mls | 4 | 6/1 | 1860 Lbs | 233 Lbs | 227 Lbs | 150 Amps | 120 Amps |
| Janthina | 1/0 | 7/w | 60 mls | 2 | 6/1 | 2850 Lbs | 376 Lbs | 365 Lbs | 205 Amps | 160 Amps |
| Ranella | 1/0 | 19/w | 60 mls | 2 | 6/1 | 2850 Lbs | 372 Lbs | 362 Lbs | 205 Amps | 160 Amps |
| Cavolinia | 2/0 | 7/w | 60 mls | 1 | 6/1 | 3550 Lbs | 462 Lbs | 451 Lbs | 235 Amps | 185 Amps |
| Clio | 2/0 | 19/w | 60 mls | 1 | 6/1 | 3550 Lbs | 458 Lbs | 446 Lbs | 235 Amps | 185 Amps |
| Sanddollar | 3/0 | 7/w | 60 mls | 1/0 | 6/1 | 4380 Lbs | 570 Lbs | 557 Lbs | 275 Amps | 215 Amps |
| Aega | 3/0 | 19/w | 60 mls | 1/0 | 6/1 | 4380 Lbs | 565 Lbs | 552 Lbs | 275 Amps | 215 Amps |
| Cuttlefish | 4/0 | 7/w | 60 mls | 2/0 | 6/1 | 5310 Lbs | 706 Lbs | 691 Lbs | 315 Amps | 245 Amps |
| Cerapus | 4/0 | 19/w | 60 mls | 2/0 | 6/1 | 5310 Lbs | 699 Lbs | 684 Lbs | 315 Amps | 245 Amps |
| Cowry | 336.4 | 19/w | 80 mls | 4/0 | 6/1 | 8350 Lbs | 1135 Lbs | 1093 Lbs | 420 Amps | 325 Amps |
| Minex | 6 | Solid | 45 mls | 6 | 7 | 1110 Lbs | 106.6 Lbs | 102.9 Lbs | 85 Amps | 70 Amps |
| Hippa | 6 | 7 | 45 mls | 6 | 7 | 1110 Lbs | 113.2 Lbs | 105.7 Lbs | 85 Amps | 70 Amps |
| Prawn | 4 | Solid | 45 mls | 4 | 7 | 1760 Lbs | 158.4 Lbs | 154.1 Lbs | 115 Amps | 90 Amps |
| Barnacles | 4 | 7 | 45 mls | 4 | 7 | 1760 Lbs | 168.3 Lbs | 158.2 Lbs | 115 Amps | 90 Amps |
| Shrimp | 2 | 7 | 45 mls | 2 | 7 | 2800 Lbs | 253.7 Lbs | 239.7 Lbs | 150 Amps | 120 Amps |
| Gammarus | 1/0 | 7 | 60 mls | 1/0 | 7 | 4460 Lbs | 411.7 Lbs | 386.0 Lbs | 205 Amps | 160 Amps |
| Leda | 1/0 | 19 | 60 mls | 1/0 | 7 | 4460 Lbs | 402.7 Lbs | 386.0 Lbs | 205 Amps | 160 Amps |
| Dungenese | 2/0 | 7 | 60 mls | 2/0 | 7 | 5390 Lbs | 506.8 Lbs | 476.3 Lbs | 235 Amps | 185 Amps |
| Cyclops | 2/0 | 19 | 60 mls | 2/0 | 7 | 5390 Lbs | 495.3 Lbs | 476.3 Lbs | 235 Amps | 185 Amps |
| Flustra | 3/0 | 19 | 60 mls | 3/0 | 7 | 6790 Lbs | 611.4 Lbs | 589.1 Lbs | 275 Amps | 215 Amps |
| Lepas | 4/0 | 19 | 60 mls | 4/0 | 7 | 8560 Lbs | 757.1 Lbs | 730.5 Lbs | 315 Amps | 245 Amps |
| Artemia | 4 | Solid | 45 mls | 6 | 7 | 1110 Lbs | 141.4 Lbs | 137.1 Lbs | 115 Amps | 90 Amps |
| Crab | 4 | 7 | 45 mls | 6 | 7 | 1110 Lbs | 151.3 Lbs | 141.2 Lbs | 115 Amps | 90 Amps |
| Solaster | 2 | 7 | 45 mls | 4 | 7 | 1760 Lbs | 226.6 Lbs | 212.6 Lbs | 150 Amps | 120 Amps |
| Sandcrab | 1/0 | 7 | 60 mls | 2 | 7 | 2800 Lbs | 368.8 Lbs | 343.1 Lbs | 205 Amps | 160 Amps |
| Echinus | 1/0 | 19 | 60 mls | 2 | 7 | 2800 Lbs | 358.8 Lbs | 343.1 Lbs | 205 Amps | 160 Amps |
| Crayfish | 2/0 | 7 | 60 mls | 1 | 7 | 3530 Lbs | 452.6 Lbs | 422.5 Lbs | 235 Amps | 185 Amps |
| Sipho | 2/0 | 19 | 60 mls | 1 | 7 | 3530 Lbs | 441.0 Lbs | 422.5 Lbs | 235 Amps | 185 Amps |
| Fulgar | 3/0 | 19 | 60 mls | 1/0 | 7 | 4460 Lbs | 543.4 Lbs | 521.1 Lbs | 275 Amps | 215 Amps |
| Arca | 4/0 | 19 | 60 mls | 2/0 | 7 | 5390 Lbs | 671.2 Lbs | 644.6 Lbs | 315 Amps | 245 Amps |
