• Model NO.：N2XH
• Material Shape：Round Wire
• Range of Application：Distribution
• Certification：ISO9001, CE, CCC
• Brand：Boan
• Rated Voltage：0.6,1 Kv
• Size：1.5-300 mm2
• Number of Cores：1-30
• Transport Package：Heated Steel-Wooden Drum,Steel Drum
• Specification：SGS
• Trademark：DingAn or OEM
• Origin：Jiangsu Yixing, China
• HS Code：8544492100
• Production Capacity：38000 Km,Year

Basic Info.

Model NO. N2XH Material Shape Round Wire Range of Application Distribution Certification ISO9001, CE, CCC Brand Boan Rated Voltage 0.6/1 Kv Size 1.5-300 mm2 Number of Cores 1-30 Transport Package Heated Steel-Wooden Drum/Steel Drum Specification SGS Trademark DingAn or OEM Origin Jiangsu Yixing, China HS Code 8544492100 Production Capacity 38000 Km/Year

Product Description

N2XH, Power Cable, 0.6/1 KV, Cu/XLPE/Lszh (VDE 0276-604)

Construction
1. Conductor: Bare copper, solid or stranded
2. Insulation: Cross-linked polyethylene, core colours acc. To HD308
3. Inner covering
4. Outer sheath: Halogen free polymer compound, black

Application
Halogen free cables with improved fire properties can be laid in interiors, in air or in concrete. Direct burial in ground or direct laying in water is not permissible. However, a laying in a pipe is allowed if water accumulations are excluded. During installation the cables have to be protected from any external influences or mechanical damages. These cables are suitable for the connection of devices of the safety class system II.

Properties
- Halogen free, no emission of corrosive gases (EN 50267-2-2, IEC 60754-2)
- Fire retardant (EN 60332-1-2, EN 60332-3-24)
- Low smoke and fume generation (EN 61034)
- Service temperature: - 30...+ 90 ° C
- Laying temperature: - 5...+ 90 ° C
- Min. Bending radius: Multicore: 12 x D
Singlecore: 15 x D

Number of cores and cross section	Outer diameter	Weight of cable	Calorific potential
mm2	approx. mm	approx. kg/km	kWh/m
1 x 4 RE	7,3	89	0,29
1 x 6 RE	7,8	112	0,33
1 x 10 RE	8,6	156	0,38
1 x 16 RM	9,8	226	0,46
1 x 25 RM	11,4	327	0,62
1 x 35 RM	12,6	429	0,71
1 x 50 RM	13,8	555	0,82
1 x 70 RM	15,7	765	1,00
1 x 95 RM	17,4	1.024	1,14
1 x 120 RM	19,0	1.263	1,32
1 x 150 RM	20,9	1.542	1,59
1 x 185 RM	23,1	1.918	1,91
1 x 240 RM	25,6	2.466	2,24
1 x 300 RM	28,1	3.065	2,58
2 x 1,5 RE	9,3	125	0,45
2 x 2,5 RE	10,1	158	0,52
3 x 1,5 RE	9,7	142	0,51
3 x 2,5 RE	10,6	184	0,59
3 x 4 RE	11,7	247	0,70
3 x 6 RE	12,8	322	0,80
3 x 10 RE	14,9	480	1,02
3 x 16 RM	17,7	732	1,36
4 x 1,5 RE	10,4	166	0,60
4 x 2,5 RE	11,4	220	0,69
4 x 4 RE	12,6	298	0,84
4 x 6 RE	13,8	391	0,95
4 x 10 RE	16,3	599	1,26
4 x 16 RM	19,2	908	1,63
4 x 25 RM	23,9	1.413	2,48
4 x 35 RM	26,7	1.863	2,93
4 x 50 SM	29,1	2.362	3,76
4 x 70 SM	32,2	3.151	4,55
4 x 95 SM	37,2	4.339	5,72
4 x 120 SM	40,8	5.332	6,36
5 x 1,5 RE	11,2	195	0,71
5 x 2,5 RE	12,3	260	0,84
5 x 4 RE	13,7	357	1,00
5 x 6 RE	15,4	486	1,21
5 x 10 RE	17,8	723	1,52
5 x 16 RM	21,6	1.138	2,07
5 x 25 RM	26,0	1.700	2,78
7 x 1,5 RE	12,0	239	0,80
10 x 1,5 RE	15,6	358	1,18
12 x 1,5 RE	16,0	395	1,29
14 x 1,5 RE	16,9	446	1,48
19 x 1,5 RE	18,6	557	1,80
24 x 1,5 RE	22,2	736	2,35
30 x 1,5 RE	23,3	857	2,72
40 x 1,5 RE	26,0	1.080	3,09
7 x 2,5 RE	13,2	323	0,93
10 x 2,5 RE	17,4	482	1,40
12 x 2,5 RE	17,9	540	1,53
14 x 2,5 RE	18,7	603	1,72
19 x 2,5 RE	21,2	796	2,18
24 x 2,5 RE	24,6	998	2,73
30 x 2,5 RE	25,9	1.176	3,17
