Ntskcgerloeu Medium Voltage Coal Cutter Cable Coal Mine Cable for The Connection of Mobile Electrical Equipment in Underground Mines
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Tinner Copper
- Sheath Material：5GM5
- Insulation Material：3G13
Base Info
- Model NO.：NTSKCGERLOEU
- Material Shape：Round Wire
- Range of Application：for The Connection of Mobile Electrical Equipment
- Certification：CE, CCC, RoHS, VDE
- Brand：Fengda
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
Basic Info.
Model NO. NTSKCGERLOEU Material Shape Round Wire Range of Application for The Connection of Mobile Electrical Equipment Certification CE, CCC, RoHS, VDE Brand Fengda Color Black Red Yellow, According to Voltage Level Whether It Is Environmentally Friendly Yes Whether Quality Inspection Provide Inspection Certificate Standard Customized According to Specified National Standar OEM/ODM Accepted Core Single Core and Multicore Transport Package Standard Export Packaging Specification International General Specifications Trademark Fengda Origin Tianjin, China(Mainland) HS Code 8544492100 Production Capacity 100000/DayProduct Description
Applications
These cables are used for the connection of mobile electrical equipment in underground mines, e.g. for coal-cutting machines, especially for the use in bretby chains with extreme bending loads under low tensile stress.
Standards
VDE 0250 Part 813
Dimensions and Weight
1.8/3KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|---|---|---|
| NO. ×MM^2 | MM | MM | KG/KM |
| 3×35+3×(1.5ST+25/3)+UEL | 44.0 | 49.0 | 3900 |
| 3×50+3×(1.5ST+25/3)+UEL | 50.0 | 55.0 | 5100 |
| 3×70+3×(1.5ST+35/3)+UEL | 52.0 | 56.0 | 6200 |
| 3×95+3×(1.5ST+50/3)+UEL | 58.0 | 62.0 | 7500 |
| 3×120+3×(1.5ST+70/3)+UEL | 64.0 | 70.0 | 9350 |
3.6/6KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|---|---|---|
| NO. ×MM^2 | MM | MM | KG/KM |
| 3×35+3×(1.5ST+25/3)+UEL | 49.0 | 54.0 | 5800 |
| 3×50+3×(1.5ST+25/3)+UEL | 56.0 | 61.0 | 6100 |
| 3×70+3×(1.5ST+35/3)+UEL | 57.0 | 62.0 | 6700 |
| 3×95+3×(1.5ST+50/3)+UEL | 62.0 | 66.0 | 8000 |
| 3×120+3×(1.5ST+70/3)+UEL | 67.0 | 71.0 | 10200 |
