Tree Wire Cable 25 Kv 3-Layer ACSR (ANSI/ICEA S-66-524)
Jiangsu Boan Cable Co., Ltd.- Rated Voltage：25 Kv
- Size Range：1,0-556.5 AWG or Kcmil
- Number of Cores：1
- Number of Wires：7-37
- Conductor Material：ACSR
- Inner Covering Material：XLPE
Base Info
- Model NO.：Tree Wire Cable
- Outer Covering Material：HDPE
- Transport Package：Heated Steel-Wooden Drum,Wooden Drum
- Specification：SGS
- Trademark：DingAn
- Origin：Jiangsu Yixing, China
- HS Code：8544492100
- Production Capacity：22000 Km
Description
| 3-Layer 25kV ACSR Tree Wire | ||||||||
| Size | Conductor Diameter | Covering Thickness | Rated Strength | Weight per 1000 ft. | ||||
| (AWG or kcmil) | Stranding | (mils) | (mils) | Cable O.D. | ||||
| Conductor Shield | Inner Layer | Outer Layer | (mils) | (lbs) | (lbs) | |||
| 1/0 | 6/1 | 398 | 15 | 125 | 125 | 928 | 4161 | 385 |
| 2/0 | 6/1 | 447 | 15 | 125 | 125 | 977 | 5045 | 443 |
| 3/0 | 6/1 | 502 | 15 | 125 | 125 | 1032 | 6289 | 513 |
| 4/0 | 6/1 | 563 | 15 | 125 | 125 | 1093 | 7933 | 600 |
| 266.8 | 18/1 | 609 | 15 | 125 | 125 | 1139 | 6536 | 608 |
| 266.8 | 26/7 | 642 | 15 | 125 | 125 | 1172 | 10735 | 692 |
| 336.4 | 18/1 | 684 | 15 | 125 | 125 | 1214 | 8246 | 714 |
| 336.4 | 26/7 | 720 | 15 | 125 | 125 | 1250 | 13395 | 818 |
| 336.4 | 30/7 | 741 | 15 | 125 | 125 | 1271 | 16435 | 1086 |
| 397.5 | 18/1 | 743 | 15 | 125 | 125 | 1273 | 9443 | 804 |
| 397.5 | 24/7 | 772 | 15 | 125 | 125 | 1302 | 13870 | 863 |
| 397.5 | 26/7 | 783 | 15 | 125 | 125 | 1313 | 15485 | 926 |
| 477 | 24/7 | 846 | 20 | 125 | 125 | 1386 | 16340 | 999 |
| 477 | 26/7 | 858 | 20 | 125 | 125 | 1398 | 18525 | 1076 |
| 477 | 30/7 | 883 | 20 | 125 | 125 | 1423 | 22610 | 1458 |
| 556.5 | 18/1 | 879 | 20 | 125 | 125 | 1419 | 13015 | 1045 |
| 556.5 | 24/7 | 914 | 20 | 125 | 125 | 1454 | 18810 | 1124 |
| 556.5 | 26/7 | 927 | 20 | 125 | 125 | 1467 | 21470 | 1213 |
