Overhead Bare Electric Cable ACSR Steel Reinforced Aluminum AAC AAAC Conductor All Aluminum Alloy Conductor
YIFANG ELECTRIC GROUP INC.- Type:Bare
- Conductor Type:Stranded
- Application:Overhead
- Conductor Material:Aluminum
- Insulation Material:Bare
- Certification:ISO9001
Base Info
- Model NO.:AAAC
- Product Name:All Aluminum Alloy Conductor AAAC Conductor
- Transport Package:wooden drum, steel drum, wooden&steel drum
- Trademark:YIFANG
- Origin:ZHENGZHOU CHINA
- HS Code:7614900000
- Production Capacity:1000 mt,month
Description
ALL ALUMINIUM ALLOY STRANDED CONDUCTOR AAACTechnical characteristics/U.S.A Sizes-ASTM B-399 Code word Conductor size Stranding Section area Diameter of conductor Linear mass Rated strength D.C. resistance at 20C AWG (MCM) No./mm mm 2 mm Kg/km kgf Ω/km Akron 7/1.68 15.51 5.04 42.7 502 2.15980 4 7/1.96 21.14 5.89 57.89 685 1.58600 Alton 48.69(4) 7/2.12 24.67 6.35 67.56 799 1.35570 2 7/2.47 33.65 7.42 92.14 1091 0.99870 Ames 77.47(2) 7/2.67 39.26 8.02 107.50 1275 0.85470 1/0 7/3.12 53.49 9.35 146.50 1733 0.62590 Azusa 123.3(1/0) 7/3. 37 62.46 10.11 171.00 2019 0.53650 2/0 7/3.50 67.45 10.52 184.70 2090 0.49740 Anaheim 155.4(2/0) 7/3.78 78.75 11.35 215.16 2447 0.42640 3/0 7/3.93 85.00 11.79 232.70 2641 0.39450 Amherst 195.7 (3/0) 7/4.25 99.20 12.75 271.50 3079 0.33730 4/0 7/4.42 107.20 13.26 293.70 3334 0.31190 Alliance 246.9 (4/0) 7/4.77 125.10 14.30 342.60 3885 0.26780 250.0 19/2.91 126.70 14.58 346.90 3977 0.26510 300.0 19/3.19 152.10 15.89 418.60 4772 0.22060 Butte 312.8 19/3.26 158.50 16.31 434.00 4976 0.21120 350.0 19/3.45 177.30 17.25 485.50 5333 0.18860 Canton 394.5 19/3.66 199.00 18.31 547.40 6016 0.16760 19/3.69 202.70 18.44 555.10 6098 0.16490 450.0 19/3.91 228.00 19.56 624.40 6862 0.14680 Cairo 465.4 19/3.98 235.80 19.89 645.70 7097 0.14310 500.0 19/4.12 253.40 20.60 693.60 7617 0.13220 550.0 37/3.10 278.70 21.67 762.90 8555 0.12000 Darien 559.5 19/4.36 283.50 21.79 776.30 8525 0.11810 660.0 37/3.23 304.00 22.63 832.00 9330 0.11050 650.0 37/3.37 329.40 23.57 909.80 10105 0.10150 Elgin 652.4 19/4.71 330.60 23.55 970.60 9942 0.10120 700.0 37/3.49 354.50 24.46 910.60 10401 0.09464 Flint 740.8 37/3.59 375.40 25.15 1028.00 11013 0.08944 750.0 37/3.62 380.20 25.32 1041.00 11216 0.08796 800.0 37/3.73 405.40 26.14 1109.00 11930 0.08285 900.0 37/3.96 456.30 27.74 1249.00 13460 0.07351 Greeley 927.2 37/4.02 469.80 28.14 1287.00 13868 0.07133 1000.0 37/4.18 506.70 29.24 1388.00 14887 0.06597 1077.4 61/3.38 483.40 30.42 1496.00 15907 0.06120 1165.1 61/3.51 523.70 31.59 1617.00 17233 0.05675 1250.0 61/3.63 633.30 32.67 1733.00 18354 0.05306 1259.6 61/3.65 564.00 32.85 1748.00 18558 0.05248 1348.8 61/3.78 604.20 34.02 1872.00 19884 0.04893 1439.2 61/3.90 644.50 35.10 1997.00 21209 0.04597 1500.0 61/3.98 760.00 35.82 2081.00 22127 0.04414 1750.0 61/4.30 886.70 38.70 2429.00 25798 0.03781
Our company
Yifang Electric group mainly specialized in wire&cables,including designment,production and sale.
Products are mainly covering low,medium,high voltage(1KV to 220KV) XLPE Insulated power cable,PVC insulated power cable,ABC cable,building cable control cable,rubber cable welding cable Etc.
Our XLPE cable can be manufactured according to the company's specification which is equivalent to IEC 60502,IEC60332,IEC60754. Some indexes are superior to above international standard.
Our certificate
FAQ
1.Q:Are you a factory or trading company?
A: Manufacturing base in Henan ,China, with more than 500 workers.
2.Q:How can I visit there?
A: Sure,If you need,we will arrange the driver to pick you up.
3.Q:How can I get some samples?
A: Contact me on below,Determin sample and address for shipping.
4.Q:Have you ever supplied cables to our country?
A: Yifang Cables have been sold to over 100 countries and regions in the world. can you contact me for details.
5.Q:What is your MOQ?
A: MOQ Normally 500 meters for big diameter cables.Please contact me for detail info if you have specific cable requirement.
6. Q:When can I get the price?
A: Usually quote within 6 hours after we get your inquiry.
7.Q:How long is your delivery time?
A: According to your order's quantity.Usually our lead time is 3 - 20 working days.
